I found some time over the holidays to finalize the Azure edition of IdentityServer.

http://identityserver.codeplex.com/releases/view/81206

The biggest difference to the on-premise version (and earlier Azure betas) is, that by default IdSrv now uses Azure Storage for all data storage (configuration & user data). This means that there is no need anymore for SQL Azure (which is still supported out of the box – just not the default anymore).

The download includes a readme file with setup instructions. In a nutshell:

• Create a new hosted service and upload your certificates
• Modify the service configuration file in the download to your needs (signing cert, connection strings to storage…)
• Deploy the package via the portal or other tools
• Use the new Powershell scripts to add users

If you encounter any problem, please give me feedback.

Friday, January 27, 2012 9:20:37 AM UTC

nice!

Monday, January 16, 2012 8:15:17 AM UTC

My last advice for 2011:

Get a ticket for Troopers 2012 before it is sold out.

If you like to learn about IPv6, Android, iOS, SAP or cloud security (and much more) – that’s the place to be!

Saturday, December 31, 2011 11:25:48 AM UTC

see here:

http://blogs.msdn.com/b/windowsazure/archive/2011/12/20/important-announcements-regarding-the-access-control-service.aspx

Wednesday, December 21, 2011 9:43:16 AM UTC

Claudio Sanchez did it again! thanks!

http://claudioasanchez.blogspot.com/2011/12/walk-though-of-provisioning-identity.html

Wednesday, December 21, 2011 9:16:00 AM UTC

http://tinyurl.com/claimsguide2

Monday, December 12, 2011 4:48:49 AM UTC

It was brought to my attention that fedutil does not work anymore with IdSrv v1 metadata. And I can confirm that.

The reason for this bug is my recent change to the XmlWriter factory methods which have a different default behavior when it comes to encoding.

Since there were only 20 downloads so far – I fixed the bug in-place (shame on me). So when you are one of the early adopters and run into this problem – just re-download IdSrv ;)

HTH

Wednesday, December 07, 2011 8:10:24 AM UTC

Yeah – it is finally done. I just uploaded the v1 bits to Codeplex and the documentation to our server. Here’s the official blurb…

Thinktecture IdentityServer is an open source security token service based on Microsoft .NET, ASP.NET MVC, WCF and WIF.

High level features

• Multiple protocols support (WS-Trust, WS-Federation, OAuth2, WRAP, JSNotify, HTTP GET)
• Multiple token support (SAML 1.1/2.0, SWT)
• Out of the box integration with ASP.NET membership, roles and profile
• Support for username/password and client certificates authentication
• Support for WS-Federation metadata
• Support for WS-Trust identity delegation
• Extensibility points to customize configuration and user management handling

Disclaimer
I did thorough testing of all features of IdentityServer - but keep in mind that this is an open source project and I am the only architect, developer and tester on the team.
IdentityServer also lacks many of the enterprise-level features like configuration services, proxy support, operations integration etc.
I only recommend using IdentityServer if you also understand how it works (to be able to support it). I am offering consulting to help you with customization and lock down - contact me.

Download. Documentation.

Up next is v1 of the Azure version. Have fun!

Tuesday, December 06, 2011 6:14:20 PM UTC

Sam Huggill wrote a great post on how to get StarterSTS working on IIS 6.

Thanks Sam!

Wednesday, November 23, 2011 3:51:49 PM UTC

In the previous post I showed how token based authentication can be implemented for WCF HTTP based services.

Authentication is the process of finding out who the user is – this includes anonymous users. Then it is up to the service to decide under which circumstances the client has access to the service as a whole or individual operations. This is called authorization.

By default – my framework does not allow anonymous users and will deny access right in the service authorization manager. You can however turn anonymous access on – that means technically, that instead of denying access, an anonymous principal is placed on Thread.CurrentPrincipal. You can flip that switch in the configuration class that you can pass into the service host/factory.

var configuration = new WebTokenWebServiceHostConfiguration
{
    AllowAnonymousAccess = true
};

But this is not enough, in addition you also need to decorate the individual operations to allow anonymous access as well, e.g.:

[AllowAnonymousAccess]
public string GetInfo()
{
    ...
}

Inside these operations you might have an authenticated or an anonymous principal on Thread.CurrentPrincipal, and it is up to your code to decide what to do.

Side note: Being a security guy, I like this opt-in approach to anonymous access much better that all those opt-out approaches out there (like the Authorize attribute – or this.).

Claims-based Authorization
Since there is a ClaimsPrincipal available, you can use the standard WIF claims authorization manager infrastructure – either declaratively via ClaimsPrincipalPermission or programmatically (see also here).

[ClaimsPrincipalPermission(SecurityAction.Demand,
    Resource = "Claims",
    Operation = "View")]
public ViewClaims GetClientIdentity()
{
    return new ServiceLogic().GetClaims();
}

In addition you can also turn off per-request authorization (see here for background) via the config and just use the “domain specific” instrumentation.

While the code is not 100% done – you can download the current solution here.

HTH

(Wanna learn more about federation, WIF, claims, tokens etc.? Click here.)

Wednesday, November 16, 2011 8:11:50 AM UTC

If you wondered how a client would have to look like to work with the authentication framework, it is pretty straightfoward:

1. Request a token
2. Put that token on the authorization header (along with a registered scheme) and make the service call

e.g.:

var oauth2 = new OAuth2Client(_oauth2Address);
var swt = oauth2.RequestAccessToken(
  "username", "password", _baseAddress.AbsoluteUri);

var client = new HttpClient { BaseAddress = _baseAddress };
client.DefaultRequestHeaders.Authorization =
  new AuthenticationHeaderValue("Bearer", swt);

var response = client.Get("identity");
response.EnsureSuccessStatusCode();

HTH

Tuesday, November 15, 2011 4:58:37 PM UTC

This post shows some of the implementation techniques for adding token and claims based security to HTTP/REST services written with WCF. For the theoretical background, see my previous post.

Disclaimer
The framework I am using/building here is not the only possible approach to tackle the problem. Based on customer feedback and requirements the code has gone through several iterations to a point where we think it is ready to handle most of the situations.

Goals and requirements

• The framework should be able to handle typical scenarios like username/password based authentication, as well as token based authentication
• The framework should allow adding new supported token types
• Should work with WCF web programming model either self-host or IIS hosted
• Service code can rely on an IClaimsPrincipal on Thread.CurrentPrincipal that describes the client using claims-based identity

Implementation overview
In WCF the main extensibility point for this kind of security work is the ServiceAuthorizationManager. It gets invoked early enough in the pipeline, has access to the HTTP protocol details of the incoming request and can set Thread.CurrentPrincipal. The job of the SAM is simple:

1. Check the Authorization header of the incoming HTTP request
2. Check if a “registered” token (more on that later) is present
3. If yes, validate the token using a security token handler, create the claims principal (including claims transformation) and set Thread.CurrentPrincipal
4. If no, set an anonymous principal on Thread.CurrentPrincipal. By default, anonymous principals are denied access – so the request ends here with a 401 (more on that later).

To wire up the custom authorization manager you need a custom service host – which in turn needs a custom service host factory. The full object model looks like this:

Token handling
A nice piece of existing WIF infrastructure are security token handlers. Their job is to serialize a received security token into a CLR representation, validate the token and turn the token into claims.

The way this works with WS-Security based services is that WIF passes the name/namespace of the incoming token to WIF’s security token handler collection. This in turn finds out which token handler can deal with the token and returns the right instances.

For HTTP based services we can do something very similar. The scheme on the Authorization header gives the service a hint how to deal with an incoming token. So the only missing link is a way to associate a token handler (or multiple token handlers) with a scheme and we are (almost) done.

WIF already includes token handler for a variety of tokens like username/password or SAML 1.1/2.0. The accompanying sample has a implementation for a Simple Web Token (SWT) token handler, and as soon as JSON Web Token are ready, simply adding a corresponding token handler will add support for this token type, too.

All supported schemes/token types are organized in a WebSecurityTokenHandlerCollectionManager and passed into the host factory/host/authorization manager.

Adding support for basic authentication against a membership provider would e.g. look like this (in global.asax):

var manager = new WebSecurityTokenHandlerCollectionManager();

manager.AddBasicAuthenticationHandler((username, password) =>
  Membership.ValidateUser(username, password));

Adding support for Simple Web Tokens with a scheme of Bearer (the current OAuth2 scheme) requires passing in a issuer, audience and signature verification key:

manager.AddSimpleWebTokenHandler(
    "Bearer",
    "http://identityserver.thinktecture.com/trust/initial",
    "https://roadie/webservicesecurity/rest/",
    "WFD7i8XRHsrUPEdwSisdHoHy08W3lM16Bk6SCT8ht6A=");

In some situations, SAML token may be used as well. The following configures SAML support for a token coming from ADFS2:

var registry = new ConfigurationBasedIssuerNameRegistry();
registry.AddTrustedIssuer(
  "d1 c5 b1 25 97 d0 36 94 65 1c e2 64 fe 48 06 01 35 f7 bd db", "ADFS");

var adfsConfig = new SecurityTokenHandlerConfiguration();
adfsConfig.AudienceRestriction.AllowedAudienceUris.Add(
  new Uri("https://roadie/webservicesecurity/rest/"));
adfsConfig.IssuerNameRegistry = registry;
adfsConfig.CertificateValidator = X509CertificateValidator.None;

// token decryption (read from config)
adfsConfig.ServiceTokenResolver =
  IdentityModelConfiguration.ServiceConfiguration.CreateAggregateTokenResolver();
manager.AddSaml11SecurityTokenHandler("SAML", adfsConfig);

Transformation
The custom authorization manager will also try to invoke a configured claims authentication manager. This means that the standard WIF claims transformation logic can be used here as well. And even better, can be also shared with e.g. a “surrounding” web application.

Error handling
A WCF error handler takes care of turning “access denied” faults into 401 status codes and a message inspector adds the registered authentication schemes to the outgoing WWW-Authenticate header when a 401 occurs.

The next post will conclude with authorization as well as the source code download.

(Wanna learn more about federation, WIF, claims, tokens etc.? Click here.)

Tuesday, November 15, 2011 4:04:12 PM UTC

WIF as it exists today is optimized for web applications (passive/WS-Federation) and SOAP based services (active/WS-Trust). While there is limited support for WCF WebServiceHost based services (for standard credential types like Windows and Basic), there is no ready to use plumbing for RESTful services that do authentication based on tokens.

This is not an oversight from the WIF team, but the REST services security world is currently rapidly changing – and that’s by design. There are a number of intermediate solutions, emerging protocols and token types, as well as some already deprecated ones. So it didn’t make sense to bake that into the core feature set of WIF.

But after all, the F in WIF stands for Foundation. So just like the WIF APIs integrate tokens and claims into other hosts, this is also (easily) possible with RESTful services. Here’s how.

HTTP Services and Authentication
Unlike SOAP services, in the REST world there is no (over) specified security framework like WS-Security. Instead standard HTTP means are used to transmit credentials and SSL is used to secure the transport and data in transit.

For most cases the HTTP Authorize header is used to transmit the security token (this can be as simple as a username/password up to issued tokens of some sort). The Authorize header consists of the actual credential (consider this opaque from a transport perspective) as well as a scheme. The scheme is some string that gives the service a hint what type of credential was used (e.g. Basic for basic authentication credentials). HTTP also includes a way to advertise the right credential type back to the client, for this the WWW-Authenticate response header is used.

So for token based authentication, the service would simply need to read the incoming Authorization header, extract the token, parse and validate it. After the token has been validated, you also typically want some sort of client identity representation based on the incoming token. This is regardless of how technology-wise the actual service was built. In ASP.NET (MVC) you could use an HttpModule or an ActionFilter. In (todays) WCF, you would use the ServiceAuthorizationManager infrastructure. The nice thing about using WCF’ native extensibility points is that you get self-hosting for free.

This is where WIF comes into play. WIF has ready to use infrastructure built-in that just need to be plugged into the corresponding hosting environment:

• Representation of identity based on claims. This is a very natural way of translating a security token (and again I mean this in the widest sense – could be also a username/password) into something our applications can work with.
• Infrastructure to convert tokens into claims (called security token handler)
• Claims transformation
• Claims-based authorization

So much for the theory. In the next post I will show you how to implement that for WCF – including full source code and samples.

(Wanna learn more about federation, WIF, claims, tokens etc.? Click here.)

Tuesday, November 15, 2011 9:25:32 AM UTC

I spend numerous hours every month answering questions about WIF and identity in general. This made me realize that this is still quite a complicated topic once you go beyond the standard fedutil stuff.

My good friend Brock and I put together a two day training course about WIF that covers everything we think is important. The course includes extensive lab material where you take standard application and apply all kinds of claims and federation techniques and technologies like WS-Federation, WS-Trust, session management, delegation, home realm discovery, multiple identity providers, Access Control Service, REST, SWT and OAuth. The lab also includes the latest version of the thinktecture identityserver and you will learn how to use and customize it.

If you are looking for an open enrollment style of training, have a look here or here. Or contact me directly!

The course outline looks as follows:

Day 1
Intro to Claims-based Identity & the Windows Identity Foundation
WIF introduces important concepts like conversion of security tokens and credentials to claims, claims transformation and claims-based authorization. In this module you will learn the basics of the WIF programming model and how WIF integrates into existing .NET code.

Externalizing Authentication for Web Applications
WIF includes support for the WS-Federation protocol. This protocol allows separating business and authentication logic into separate (distributed) applications. The authentication part is called identity provider or in more general terms - a security token service. This module looks at this scenario both from an application and identity provider point of view and walks you through the necessary concepts to centralize application login logic both using a standard product like Active Directory Federation Services as well as a custom token service using WIF’s API support.

Externalizing Authentication for SOAP Services
One big benefit of WIF is that it unifies the security programming model for ASP.NET and WCF. In the spirit of the preceding modules, we will have a look at how WIF integrates into the (SOAP) web service world. You will learn how to separate authentication into a separate service using the WS-Trust protocol and how WIF can simplify the WCF security model and extensibility API.

Day 2
Advanced Topics:  Security Token Service Architecture, Delegation and Federation
The preceding modules covered the 80/20 cases of WIF in combination with ASP.NET and WCF. In many scenarios this is just the tip of the iceberg. Especially when two business partners decide to federate, you usually have to deal with multiple token services and their implications in application design. Identity delegation is a feature that allows transporting the client identity over a chain of service invocations to make authorization decisions over multiple hops. In addition you will learn about the principal architecture of a STS, how to customize the one that comes with this training course, as well as how to build your own.

Outsourcing Authentication:  Windows Azure & the Azure AppFabric Access Control Service
Microsoft provides a multi-tenant security token service as part of the Azure platform cloud offering. This is an interesting product because it allows to outsource vital infrastructure services to a managed environment that guarantees uptime and scalability. Another advantage of the Access Control Service is, that it allows easy integration of both the “enterprise” protocols like WS-* as well as “web identities” like LiveID, Google or Facebook into your applications. ACS acts as a protocol bridge in this case where the application developer doesn’t need to implement all these protocols, but simply uses a service to make it happen.

Claims & Federation for the Web and Mobile World
Also the web & mobile world moves to a token and claims-based model. While the mechanics are almost identical, other protocols and token types are used to achieve better HTTP (REST) and JavaScript integration for in-browser applications and small footprint devices. Also patterns like how to allow third party applications to work with your data without having to disclose your credentials are important concepts in these application types. The nice thing about WIF and its powerful base APIs and abstractions is that it can shield application logic from these details while you can focus on implementing the actual application.

HTH

Wednesday, November 09, 2011 8:18:16 AM UTC

ADFS uses SSL extended protection which made observing traffic with Fiddler harder to impossible.

Fortunately, this can be fixed – Eric Lawrence writes about it here.

Sunday, November 06, 2011 12:01:23 PM UTC

I just uploaded a new version of the sample relying party. The three changes are:

• Added a session token diagnostics page. This allows to look at cookie sizes, details and the raw contents
• Sample code to switch to session mode
• Sample code to implement sliding expiration

This was already included since 1.0:

• WS-Federation example
• Claims viewer
• Token viewer
• Active sign in via WS-Trust
• Delegation

HTH

Wednesday, November 02, 2011 6:28:55 PM UTC

To make it short: to switch to SessionMode (cache to server) in ASP.NET, you need to handle an event and set a property. Sounds easy – but you need to set it in the right place.

The most popular blog post about this topic is from Vittorio. He advises to set IsSessionMode in WSFederationAuthenticationModule_SessionSecurityTokenCreated.

Now there were some open questions on forum, like this one. So I decided to try it myself – and indeed it didn’t work for me as well. So I digged a little deeper, and after some trial and error I found the right place (in global.asax):

void WSFederationAuthenticationModule_SecurityTokenValidated(
  object sender, SecurityTokenValidatedEventArgs e)
{
    FederatedAuthentication.SessionAuthenticationModule.IsSessionMode = true;
}

Not sure if anything has changed since Vittorio’s post – but this worked for me.

While playing around, I also wrote a little diagnostics tool that allows you to look into the session cookie (for educational purposes). Will post that soon.

HTH

Wednesday, November 02, 2011 3:55:40 PM UTC

This fell through the cracks over the summer holiday time:

The 2nd edition of the Patterns & Practices “claims guide” has been released. This is excellent!

We added a lot of content around ADFS, Access Control Service, REST and SharePoint. All source code is available as well!

Grab it from: http://msdn.microsoft.com/en-us/library/ff423674.aspx

Or use my vanity URL: http://tinyurl.com/claimsguide

Friday, October 28, 2011 7:49:30 AM UTC

Brian has posted a great walkthrough on how to setup idsrv in conjunction with SharePoint. Thanks!

http://sharepintblog.com/2011/10/23/sharepoint-claims-based-authentication-with-thinktecture-identity-server-walkthrough/

Monday, October 24, 2011 2:13:14 PM UTC

I just uploaded the RC of IdentityServer to Codeplex.

This release is feature complete and if I don’t get any bug reports this is also pretty much the final V1.

Changes from B1

• The configuration data access is now based on EF 4.1 code first. This makes it much easier to use different data stores. For RTM I will also provide a SQL script for SQL Server so you can move the configuration to a separate machine (e.g. for load balancing scenarios).
• I included the ASP.NET Universal Providers in the download. This adds official support for SQL Azure, SQL Server and SQL Compact for the membership, roles and profile features. Unfortunately the Universal Provider use a different schema than the original ASP.NET providers (that sucks btw!) – so I made them optional. If you want to use them go to web.config and uncomment the new provider.
• The relying party registration entries now have added fields to add extra data that you want to couple with the RP. One use case could be to give the UI a hint how the login experience should look like per RP. This allows to have a different look and feel for different relying parties. I also included a small helper API that you can use to retrieve the RP record based on the incoming WS-Federation query string.
• WS-Federation single sign out is now conforming to the spec.
• Certificate based endpoint identities for SSL endpoints are optional now.
• Added a initial configuration “wizard”. This sets up the signing certificate, issuer URI and site title on the first run.

Installation

This is still a “developer” release – that means it ships with source code that you have to build it etc. But from that point it should be a little more straightforward as it used to be:

• Make sure SSL is configured correctly for IIS
• Map the WebSite directory to a vdir in IIS
• Run the web site. This should bring up the initial configuration
• Make sure the worker process account has access to the signing certificate private key
• Make sure all your users are in the “IdentityServerUsers” role in your role store. Administrators need the “IdentityServerAdministrators” role

That should be it. A proper documentation will be hopefully available soon (any volunteers?).

Please provide feedback! thanks!

Friday, October 21, 2011 6:43:14 AM UTC

I got asked today if I could publish a roadmap for thinktecture IdentityServer (idrsv in short).

Well – I got a lot of feedback after B1 and one of the biggest points here was the data access layer. So I made two changes:

• I moved to configuration database access code to EF 4.1 code first. That makes it much easier to change the underlying database. So it is now just a matter of changing the connection string to use real SQL Server instead of SQL Compact. Important when you plan to do scale out.
• I included the ASP.NET Universal Providers in the download. This adds official support for SQL Azure, SQL Server and SQL Compact for the membership, roles and profile features. Unfortunately the Universal Provider use a different schema than the original ASP.NET providers (that sucks btw!) – so I made them optional. If you want to use them go to web.config and uncomment the new provider.

Then there are some other small changes:

• The relying party registration entries now have added fields to add extra data that you want to couple with the RP. One use case could be to give the UI a hint how the login experience should look like per RP. This allows to have a different look and feel for different relying parties. I also included a small helper API that you can use to retrieve the RP record based on the incoming WS-Federation query string.
• WS-Federation single sign out is now conforming to the spec.
• I made certificate based endpoint identities for SSL endpoints optional. This caused some problems with configuration and versioning of existing clients.

I hope I can release the RC in the next days. If there are no major issues, there will be RTM very soon!

Thursday, October 06, 2011 5:01:09 PM UTC

Claudio Sanchez has created a little walkthrough for installing IdentityServer. While he uses B1 refresh, I anticipate no changes for RTM (which is sitting here on my hard drive almost ready for publishing).

Thanks Claudio!

Thursday, September 29, 2011 10:35:13 PM UTC

• WindowsIdentity, FormsIdentity and GenericIdentity now derive from ClaimsIdentity
• WindowsIdentity.GetCurrent() converts Windows token details (groups for the current Windows versions) to claims.
• Claims for Windows identities now distinguish between user claims and device claims (Windows 8 feature)
• WCF now populates Thread.CurrentPrincipal with a ClaimsPrincipal derived type

Tuesday, September 20, 2011 12:32:00 PM UTC

• System.Security.Claims has ClaimsIdentity & ClaimsPrincipal
• IClaimsIdentity & IClaimsPrincipal are gone. The classes implement IIdentity & IPrincipal now directly
• All the token handler and low level plumbing is now in System.IdentityModel

Monday, September 19, 2011 6:20:42 PM UTC

There was not a ton of new information about WIF and related technologies at Build, but Samuel Devasahayam did a great talk about claims-based access control that contained some very interesting bits of information with regards to future directions.

From his slides:

Windows 8

• Bring existing identity claims model into the Windows platform
• Domain controller issues groups & claims
• Claims (user and device) sourced from identity attributes in AD
• Claims delivered in Kerberos PAC
• NT Token has a new claims section
• Enhanced SDDL API’s to work with claims
• Enhanced user mode CheckAccess API’s to work with claims
• New ACL-UX
• Target audits with claims-based expressions

WIF & .NET 4.5

• WIF is in the box with .NET Framework 4.5
• Every principal in .NET 4.5 is a ClaimsPrincipal

ADFS 2.1

• ADFS 2.1 is available now as a in-box server role in Windows 8
• Adds support for issuing device claims from Kerberos ticket

Saturday, September 17, 2011 6:30:36 AM UTC

I uploaded a sample RP for IdentityServer. It shows some basic things like connecting a web application via WS-Federation and a SOAP service via WS-Trust.

Wednesday, July 06, 2011 6:59:33 AM UTC

Ingo Rammer
Hardcore Production Debugging
HTML5 - Offline Business Applications for Desktops, Tablets and Phones

Oliver Sturm
Functional Programming in C#
Function Programming in F#

Dominick Baier
Architecting Claims-aware Applications (with the Windows Identity Foundation and Active Directory Federation Services)
Securing REST-Services and Web-APIs

Monday, July 04, 2011 12:21:15 PM UTC

Seems to be radio week this week…

Another interview I did quite a while ago with Michele and Patrick…

http://www.lockdownpodcast.com/default.aspx?ShowNum=4

Thursday, June 23, 2011 8:50:39 PM UTC

Here you can find my updated ACS2 sample. In addition to the existing front ends (web [WS-Federation], console [SOAP & REST], Silverlight [REST]) and error handling, it now also includes a WPF client that shows the passive/active transition with a SOAP service as illustrated here.

All the ACS interaction is encapsulated in a WPF user control that:

• retrieves the JSON feed
• displays a list of supported identity providers
• triggers the sign in via a browser control
• retrieves the token response
• packages the token as a GenericXmlSecurityToken (to be used directly with the WIF ChannelFactory extensions methods)

All you need to supply is the ACS namespace and the realm.

Have fun!

Thursday, June 23, 2011 10:46:06 AM UTC

In my last post I showed you that different redirect URLs trigger different response behaviors in ACS. Where did I actually get these URLs from?

The answer is simple – I asked ACS ;)

ACS publishes a JSON encoded feed that contains information about all registered identity providers, their display names, logos and URLs. With that information you can easily write a discovery client which, at the very heart, does this:

public void GetAsync(string protocol)
{
    var url = string.Format(
      "https://{0}.{1}/v2/metadata/IdentityProviders.js?protocol={2}&realm={3}&version=1.0",
        AcsNamespace,
        "accesscontrol.windows.net",
        protocol,
        Realm);

    _client.DownloadStringAsync(new Uri(url));
}

The protocol can be one of these two values: wsfederation or javascriptnotify. Based on that value, the returned JSON will contain the URLs for either the redirect or notify method.

Now with the help of some JSON serializer you can turn that information into CLR objects and display them in some sort of selection dialog.

The next post will have a demo and source code.

Thursday, June 23, 2011 5:24:27 AM UTC

I met Carl and Richard at NDC, so we took the chance to have another chat about my favourite topic: claims ;)

http://www.dotnetrocks.com/default.aspx?showNum=674

Have fun!

Thursday, June 23, 2011 5:00:20 AM UTC

As I mentioned in my last post, ACS features a number of ways to transition between protocol and token types. One not so widely known transition is between passive sign ins (browser) and active service consumers. Let’s see how this works.

We all know the usual WS-Federation handshake via passive redirect. But ACS also allows driving the sign in process yourself via specially crafted WS-Federation query strings. So you can use the following URL to sign in using LiveID via ACS. ACS will then redirect back to the registered reply URL in your application:

GET /login.srf?
  wa=wsignin1.0&
  wtrealm=https%3a%2f%2faccesscontrol.windows.net%2f&
  wreply=https%3a%2f%2fleastprivilege.accesscontrol.windows.net%3a443%2fv2%2fwsfederation&
  wp=MBI_FED_SSL&
  wctx=pr%3dwsfederation%26rm%3dhttps%253a%252f%252froadie%252facs2rp%252frest%252f

The wsfederation bit in the wctx parameter indicates, that the response to the token request will be transmitted back to the relying party via a POST.

So far so good – but how can an active client receive that token now?

ACS knows an alternative way to send the token request response. Instead of doing the redirect back to the RP, it emits a page that in turn echoes the token response using JavaScript’s window.external.notify. The URL would look like this:

ACS would then render a page that contains the following script block:

<script type="text/javascript">
    try{
        window.external.Notify('token_response');
    }
    catch(err){
        alert("Error ACS50021: windows.external.Notify is not registered.");
    }
</script>

Whereas token_response is a JSON encoded string with the following format:

{
  "appliesTo":"...",
  "context":null,
  "created":123,
  "expires":123,
  "securityToken":"...",
  "tokenType":"..."
}

OK – so how does this all come together now?

As an active client (Silverlight, WPF, WP7, WinForms etc). application, you would host a browser control and use the above URL to trigger the right series of redirects. All the browser controls support one way or the other to register a callback whenever the window.external.notify function is called. This way you get the JSON string from ACS back into the hosting application – and voila you have the security token.

When you selected the SWT token format in ACS – you can use that token e.g. for REST services. When you have selected SAML, you can use the token e.g. for SOAP services.

In the next post I will show how to retrieve these URLs from ACS and a practical example using WPF.

Wednesday, June 22, 2011 6:04:27 PM UTC

My good friend Heimo started blogging. Given his vast arsenal of cameras and lenses, this should be an interesting read…

http://monoflop.blogspot.com/

Wednesday, June 22, 2011 9:18:37 AM UTC

ACS v2 supports a number of protocols (WS-Federation, WS-Trust, OpenId, OAuth 2 / WRAP) and a number of token types (SWT, SAML 1.1/2.0) – see Vittorio’s Infographic here. Some protocols are designed for active client (WS-Trust, OAuth / WRAP) and some are designed for passive clients (WS-Federation, OpenID).

One of the most obvious advantages of ACS is that it allows to transition between various protocols and token types. Once example would be using WS-Federation/SAML between your application and ACS to sign in with a Google account. Google is using OpenId and non-SAML tokens, but ACS transitions into WS-Federation and sends back a SAML token. This way you application only needs to understand a single protocol whereas ACS acts as a protocol bridge (see my ACS2 sample here).

Another example would be transformation of a SAML token to a SWT. This is achieved by using the WRAP endpoint – you send a SAML token (from a registered identity provider) to ACS, and ACS turns it into a SWT token for the requested relying party, e.g. (using the WrapClient from Thinktecture.IdentityModel):

[TestMethod]
public void GetClaimsSamlToSwt()
{
    // get saml token from idp
    var samlToken = Helper.GetSamlIdentityTokenForAcs();

    // send to ACS for SWT converion
    var swtToken = Helper.GetSimpleWebToken(samlToken);

    var client = new HttpClient(Constants.BaseUri);
    client.SetAccessToken(swtToken, WebClientTokenSchemes.OAuth);

    // call REST service with SWT
    var response = client.Get("wcf/client");

    Assert.AreEqual<HttpStatusCode>(HttpStatusCode.OK, response.StatusCode);
}

There are more protocol transitions possible – but they are not so obvious. A popular example would be how to call a REST/SOAP service using e.g. a LiveId login. In the next post I will show you how to approach that scenario.

Wednesday, June 22, 2011 6:49:32 AM UTC

I just uploaded a new version to codeplex and nuget (Thinktecture.IdentityModel).

Besides some bug fixes and clean up I added the ProtectedCookie feature and some more extension methods.

Friday, June 17, 2011 2:48:34 PM UTC

That’s a very common one:

public static IClaimsPrincipal ToClaimsPrincipal(
  this SecurityToken token, X509Certificate2 signingCertificate)
{
    var configuration = CreateStandardConfiguration(signingCertificate);
    return token.ToClaimsPrincipal(configuration.CreateDefaultHandlerCollection());
}

public static IClaimsPrincipal ToClaimsPrincipal(this SecurityToken token,
  X509Certificate2 signingCertificate, string audienceUri)
{
    var configuration = CreateStandardConfiguration(signingCertificate);

    configuration.AudienceRestriction.AudienceMode = AudienceUriMode.Always;
    configuration.AudienceRestriction.AllowedAudienceUris.Add(new Uri(audienceUri));

    return token.ToClaimsPrincipal(configuration.CreateDefaultHandlerCollection());
}

public static IClaimsPrincipal ToClaimsPrincipal(
  this SecurityToken token, SecurityTokenHandlerCollection handler)
{
    var ids = handler.ValidateToken(token);
    return ClaimsPrincipal.CreateFromIdentities(ids);
}

private static SecurityTokenHandlerConfiguration CreateStandardConfiguration(
  X509Certificate2 signingCertificate)

private static IssuerNameRegistry CreateIssuerNameRegistry(this X509Certificate2 certificate)
{
    var registry = new ConfigurationBasedIssuerNameRegistry();
    registry.AddTrustedIssuer(certificate.Thumbprint, certificate.Subject);

    return registry;
}

private static SecurityTokenResolver CreateSecurityTokenResolver(
  this X509Certificate2 certificate)
{
    var tokens = new List<SecurityToken>
    {
        new X509SecurityToken(certificate)
    };

    return SecurityTokenResolver.CreateDefaultSecurityTokenResolver(tokens.AsReadOnly(), true);
}

private static SecurityTokenHandlerCollection CreateDefaultHandlerCollection(
  this SecurityTokenHandlerConfiguration configuration)
{
    return
      SecurityTokenHandlerCollection.CreateDefaultSecurityTokenHandlerCollection(configuration);
}

Friday, June 17, 2011 6:50:51 AM UTC

This is a useful tool to accomplish this:

http://sqlazuremw.codeplex.com

Thursday, June 09, 2011 12:22:03 PM UTC

I recorded a short screencast about the Windows Azure Edition of IdentityServer. It includes a quick walkthrough of the solution and setup instructions.

http://identity.thinktecture.com/download/identityserver/WindowsAzureEditionB1.wmv

Monday, June 06, 2011 8:55:09 PM UTC

Every once in a while you run into a situation where you need to temporarily store data for a user in a web app. You typically have two options here – either store server-side or put the data into a cookie (if size permits).

When you need web farm compatibility in addition – things become a little bit more complicated because the data needs to be available on all nodes. In my case I went for a cookie – but I had some requirements

• Cookie must be protected from eavesdropping (sent only over SSL) and client script
• Cookie must be encrypted and signed to be protected from tampering with
• Cookie might become bigger than 4KB – some sort of overflow mechanism would be nice

I really didn’t want to implement another cookie protection mechanism – this feels wrong and btw can go wrong as well.

WIF to the rescue. The session management feature already implements the above requirements but is built around de/serializing IClaimsPrincipals into cookies and back. But if you go one level deeper you will find the CookieHandler and CookieTransform classes which contain all the needed functionality.

public class ProtectedCookie
{
    private List<CookieTransform> _transforms;
    private ChunkedCookieHandler _handler = new ChunkedCookieHandler();

    // DPAPI protection (single server)
    public ProtectedCookie()
    {
        _transforms = new List<CookieTransform>
            {
                new DeflateCookieTransform(),
                new ProtectedDataCookieTransform()
            };
    }

    // RSA protection (load balanced)
    public ProtectedCookie(X509Certificate2 protectionCertificate)
    {
        _transforms = new List<CookieTransform>
            {
                new DeflateCookieTransform(),
                new RsaSignatureCookieTransform(protectionCertificate),
                new RsaEncryptionCookieTransform(protectionCertificate)
            };
    }

    // custom transform pipeline
    public ProtectedCookie(List<CookieTransform> transforms)
    {
        _transforms = transforms;
    }

    public void Write(string name, string value, DateTime expirationTime)
    {
        byte[] encodedBytes = EncodeCookieValue(value);

        _handler.Write(encodedBytes, name, expirationTime);
    }

    public void Write(string name, string value, DateTime expirationTime,
      string domain, string path)
    {
        byte[] encodedBytes = EncodeCookieValue(value);

        _handler.Write(encodedBytes,
                       name,
                       path,
                       domain,
                       expirationTime,
                       true,
                       true,
                       HttpContext.Current);
    }

    public string Read(string name)
    {
        var bytes = _handler.Read(name);

        if (bytes == null || bytes.Length == 0)
        {
            return null;
        }

        return DecodeCookieValue(bytes);
    }

    public void Delete(string name)
    {
        _handler.Delete(name);
    }

    protected virtual byte[] EncodeCookieValue(string value)
    {
        var bytes = Encoding.UTF8.GetBytes(value);
        byte[] buffer = bytes;

        foreach (var transform in _transforms)
        {
            buffer = transform.Encode(buffer);
        }

        return buffer;
    }

    protected virtual string DecodeCookieValue(byte[] bytes)
    {
        var buffer = bytes;

        for (int i = _transforms.Count; i > 0; i—)
        {
            buffer = _transforms[i - 1].Decode(buffer);
        }

        return Encoding.UTF8.GetString(buffer);
    }
}

HTH

Wednesday, June 01, 2011 5:04:53 AM UTC

I just uploaded two new releases to Codeplex.

IdentityServer B1 refresh
A number of bug fixes and streamlined extensibility interfaces. Mostly a result of adding the Windows Azure support.

Nothing has changed with regards to setup. Make sure you watch the intro video on the Codeplex site.

IdentityServer B1 (Windows Azure Edition)
I have now implemented all repositories for Windows Azure backed data storage. The default setup assumes you use the ASP.NET SQL membership provider database in SQL Azure and Table Storage for relying party, client certificates and delegation settings.

The setup is simple:

• Upload your SSL/signing certificate via the portal
• Adjust the .cscfg file – you need to insert your storage account, certificate thumbprint and distinguished name
• There is a setup tool that can automatically insert the certificate distinguished names into your config file
• Adjust the connection string for the membership database in WebSite\configuration\connectionString.config
• Deploy

Feedback
Feature-wise this looks like the V1 release to me. It would be great if you could give me feedback, when you find a bug etc. – especially:

• Do the built-in repository implementations work for you (both on-premise and Azure)?
• Are the repository interfaces enough to add you own data store or feature?

Tuesday, May 31, 2011 8:55:47 PM UTC

In IdentityServer I don’t use Forms Authentication but the session facility from WIF. That also means that I implemented my own redirect logic to a login page when needed.

To achieve that I turned off the built-in authentication (authenticationMode="none") and added an Application_EndRequest handler that checks for 401s and does the redirect to my sign in route. The redirect only happens for web pages and not for web services.

This all works fine in local IIS – but in the Azure Compute Emulator and Windows Azure many of my tests are failing and I suddenly see 302 status codes where I expected 401s (the web service calls). After some debugging kung-fu and enabling FREB I found out, that there is still the Forms Authentication module in effect turning 401s into 302s. My EndRequest handler never sees a 401 (despite turning forms auth off in config)!

Not sure what’s going on (I suspect some inherited configuration that gets in my way here). Even if it shouldn’t be necessary, an explicit removal of the forms auth module from the module list fixed it, and I now have the same behavior in local IIS and Windows Azure. strange.

<modules>
  <remove name="FormsAuthentication" />
</modules>

HTH

Update: Brock ran into the same issue, and found the real reason. Read here.

Tuesday, May 31, 2011 4:42:55 AM UTC

Another common problem with external authentication is how to deal with sign in errors. In active federation like WS-Trust there are well defined SOAP faults to communicate problem to a client.

But with web applications, the error information is typically generated and displayed on the external sign in page. The relying party does not know about the error, nor can it help the user in any way.

The Access Control Service allows to post sign in errors to a specified page. You setup this page in the relying party registration. That means that whenever an error occurs in ACS, the error information gets packaged up as a JSON string and posted to the page specified. This way you get structued error information back into you application so you can display a friendlier error message or log the error.

I added error page support to my ACS2 sample, which can be downloaded here.

How to turn the JSON error into CLR types
The JSON schema is reasonably simple, the following class turns the JSON into an object:

[DataContract]
public class AcsErrorResponse
{
    [DataMember(Name = "context", Order = 1)]
    public string Context { get; set; }

    [DataMember(Name = "httpReturnCode", Order = 2)]
    public string HttpReturnCode { get; set; }

    [DataMember(Name = "identityProvider", Order = 3)]
    public string IdentityProvider { get; set; }

    [DataMember(Name = "timeStamp", Order = 4)]
    public string TimeStamp { get; set; }

    [DataMember(Name = "traceId", Order = 5)]
    public string TraceId { get; set; }

    [DataMember(Name = "errors", Order = 6)]
    public List<AcsError> Errors { get; set; }

    public static AcsErrorResponse Read(string json)
    {
        var serializer = new DataContractJsonSerializer(
          typeof(AcsErrorResponse));
        var response = serializer.ReadObject(
          new MemoryStream(Encoding.Default.GetBytes(json))) as AcsErrorResponse;

        if (response != null)
        {
            return response;
        }
        else
        {
            throw new ArgumentException("json");
        }
    }
}

[DataContract]
public class AcsError
{
    [DataMember(Name = "errorCode", Order = 1)]
    public string Code { get; set; }

    [DataMember(Name = "errorMessage", Order = 2)]
    public string Message { get; set; }
}

Retrieving the error information
You then need to provide a page that takes the POST and deserializes the information. My sample simply fills a view that shows all information. But that’s for diagnostic/sample purposes only. You shouldn’t show the real errors to your end users.

public class SignInErrorController : Controller
{
    [HttpPost]
    public ActionResult Index()
    {
        var errorDetails = Request.Form["ErrorDetails"];
        var response = AcsErrorResponse.Read(errorDetails);

        return View("SignInError", response);
    }
}

Also keep in mind that the error page is an anonymous page and that you are taking external input. So all the usual input validation applies.

Sunday, May 29, 2011 8:16:05 AM UTC

I really like ACS2. One feature that is very useful is home realm discovery. ACS provides a Nascar style list as well as discovery based on email addresses. You can take control of the home realm selection process yourself by downloading the JSON feed or by manually setting the home realm parameter.

Plenty of options – the only option missing is turning it off…

In other words, when you setup your ACS namespace and realm and register identity provider, there is no way to keep the list of identity providers secret. An interested “user” can always retrieve all registered identity provider (using the browser or download the JSON feed).

This may not be an issue with web identity providers, but when you use ACS to federate with customers or business partners, you maybe don’t want to disclose that list to the public (or to other customers). This is an adoption blocker for certain situations.

I hope this feature will be added soon.

In addition I would also like to see a feature I call “home realm aliases”. Some random string that I can use as a whr parameter instead of using the real issuer URI.

Tuesday, May 24, 2011 6:58:59 PM UTC

Over the weekend I worked a little more on my ACS2 sample. Instead of writing it all down, I decided to quickly record four short videos that cover the relevant features and code. Have fun ;)

Part 1 – Overview
This video does a quick walkthrough of the solution and shows the web application part. This includes driving the sign in UI via JavaScript (thanks Matias) as well as the registration logic I wrote about here.

watch

Part 2 – SOAP Service and Client
The sample app also exposes a WCF SOAP service. This video shows how to wire up the service to ACS and hows how to create a client that first requests a token from an IdP and then sends this token to ACS.

watch

Part 3 – REST Service and Client
This part shows how to set up a WCF REST service that consumes SWT tokens from ACS. Unfortunately there is currently no standard WIF plumbing for REST. For the service integration I had to combine a lot of code from different sources (kzu, zulfiq) as well as the WIF SDK and OAuth CTPs together. But it is working.

watch

Part 4 – Silverlight and Web Identity Integration
This part took by far the most time to write. The Silverlight Client shows ho to sign in to the application using a registered identity provider (including web identities) and using the resulting SWT token to call our REST service. This is designed to be a desktop (OOB) client application (thanks to Jörg for the UI magic).

watch

code download

Tuesday, May 24, 2011 11:40:27 AM UTC

Delegation using the ActAs approach has some interesting security features

• A security token service can make authorization and validation checks before issuing the ActAs token.
• Combined with proof keys you get non-repudiation features.
• The ultimate receiver sees the original caller as direct caller and can optionally traverse the delegation chain.
• Encryption and audience restriction can be tied down

Most samples out there (including the SDK sample) use the CreateChannelActingAs extension method from WIF to request ActAs tokens. This method builds on top of the WCF binding configuration which may not always be suitable for your situation.

You can also use the WSTrustChannel to request ActAs tokens. This allows direct and programmatic control over bindings and configuration and is my preferred approach.

The below method requests an ActAs token based on a bootstrap token. The returned token can then directly be used with the CreateChannelWithIssued token extension method.

private SecurityToken GetActAsToken(SecurityToken bootstrapToken)
{
    var factory = new WSTrustChannelFactory(
        new UserNameWSTrustBinding(SecurityMode.TransportWithMessageCredential),
        new EndpointAddress(_stsAddress));
    factory.TrustVersion = TrustVersion.WSTrust13;

    factory.Credentials.UserName.UserName = "middletier";
    factory.Credentials.UserName.Password = "abc!123";


    var rst = new RequestSecurityToken
    {
        AppliesTo = new EndpointAddress(_serviceAddress),

        RequestType = RequestTypes.Issue,
        KeyType = KeyTypes.Symmetric,
        ActAs = new SecurityTokenElement(bootstrapToken)
    };

    var channel = factory.CreateChannel();
    var delegationToken = channel.Issue(rst);

    return delegationToken;
}

HTH

Tuesday, May 24, 2011 6:53:11 AM UTC

You can download the full solution here.

The relevant parts in the sample are:

Configuration
I use the standard WIF configuration with passive redirect. This kicks automatically in, whenever authorization fails in the application (e.g. when the user tries to get to an area the requires authentication or needs registration).

Checking and transforming incoming claims
In the claims authentication manager we have to deal with two situations. Users that are authenticated but not registered, and registered (and authenticated) users. Registered users will have claims that come from the application domain, the claims of unregistered users come directly from ACS and get passed through. In both case a claim for the unique user identifier will be generated. The high level logic is as follows:

public override IClaimsPrincipal Authenticate(
  string resourceName, IClaimsPrincipal incomingPrincipal)
{
    // do nothing if anonymous request
    if (!incomingPrincipal.Identity.IsAuthenticated)
    {
        return base.Authenticate(resourceName, incomingPrincipal);
    }

    string uniqueId = GetUniqueId(incomingPrincipal);

    // check if user is registered
    RegisterModel data;
    if (Repository.TryGetRegisteredUser(uniqueId, out data))
    {
        return CreateRegisteredUserPrincipal(uniqueId, data);
    }

    // authenticated by ACS, but not registered
    // create unique id claim
    incomingPrincipal.Identities[0].Claims.Add(
      new Claim(Constants.ClaimTypes.Id, uniqueId));
    return incomingPrincipal;
}

User Registration
The registration page is handled by a controller with the [Authorize] attribute. That means you need to authenticate before you can register (crazy eh? ;). The controller then fetches some claims from the identity provider (if available) to pre-fill form fields.

After successful registration, the user is stored in the local data store and a new session token gets issued. This effectively replaces the ACS claims with application defined claims without requiring the user to re-signin.

Authorization
All pages that should be only reachable by registered users check for a special application defined claim that only registered users have. You can nicely wrap that in a custom attribute in MVC:

[RegisteredUsersOnly]
public ActionResult Registered()
{
    return View();
}

HTH

Saturday, May 21, 2011 4:51:56 PM UTC

ACS v2 support two fundamental types of client identities– I like to call them “enterprise identities” (WS-*) and “web identities” (Google, LiveID, OpenId in general…).

I also see two different “mind sets” when it comes to application design using the above identity types:

• Enterprise identities – often the fact that a client can present a token from a trusted identity provider means he is a legitimate user of the application. Trust relationships and authorization details have been negotiated out of band (often on paper).
• Web identities – the fact that a user can authenticate with Google et al does not necessarily mean he is a legitimate (or registered) user of an application. Typically additional steps are necessary (like filling out a form, email confirmation etc).

Sometimes also a mixture of both approaches exist, for the sake of this post, I will focus on the web identity case.

I got a number of questions how to implement the web identity scenario and after some conversations it turns out it is the old authentication vs. authorization problem that gets in the way.

Many people use the IsAuthenticated property on IIdentity to make security decisions in their applications (or deny user=”?” in ASP.NET terms). That’s a very natural thing to do, because authentication was done inside the application and we knew exactly when the IsAuthenticated condition is true. Been there, done that. Guilty ;)

The fundamental difference between these “old style” apps and federation is, that authentication is not done by the application anymore. It is done by a third party service, and in the case of web identity providers, in services that are not under our control (nor do we have a formal business relationship with these providers).

Now the issue is, when you switch to ACS, and someone with a Google account authenticates, indeed IsAuthenticated is true – because that’s what he is! This does not mean, that he is also authorized to use the application. It just proves he was able to authenticate with Google. Now this obviously leads to confusion.

How can we solve that?
Easy answer: We have to deal with authentication and authorization separately. Job done ;)

For many application types I see this general approach:

• Application uses ACS for authentication (maybe both enterprise and web identities, we focus on web identities but you could easily have a dual approach here)
• Application offers to authenticate (or sign in) via web identity accounts like LiveID, Google, Facebook etc.
• Application also maintains a database of its “own” users. Typically you want to store additional information about the user

In such an application type it is important to have a unique identifier for your users (think the primary key of your user database). What would that be?

Most web identity provider (and all the standard ACS v2 supported ones) emit a NameIdentifier claim. This is a stable ID for the client (scoped to the relying party – more on that later). Furthermore ACS emits a claims identifying the identity provider (like the original issuer concept in WIF). When you combine these two values together, you can be sure to have a unique identifier for the user, e.g.:

Facebook-134952459903700\799880347

You can now check on incoming calls, if the user is already registered and if yes, swap the ACS claims with claims coming from your user database. One claims would maybe be a role like “Registered User” which can then be easily used to do authorization checks in the application. The WIF claims authentication manager is a perfect place to do the claims transformation.

If the user is not registered, show a register form. Maybe you can use some claims from the identity provider to pre-fill form fields. (see here where I show how to use the Facebook API to fetch additional user properties). After successful registration (which may include other mechanisms like a confirmation email), flip the bit in your database to make the web identity a registered user.

This is all very theoretical. In the next post I will show some code and provide a download link for the complete sample.

More on NameIdentifier
Identity providers “guarantee” that the name identifier for a given user in your application will always be the same. But different applications (in the case of ACS – different ACS namespaces) will see different name identifiers. This is by design to protect the privacy of users because identical name identifiers could be used to create “profiles” of some sort for that user. In technical terms they create the name identifier approximately like this:

name identifier = Hash((Provider Internal User ID) + (Relying Party Address))

Why is this important to know? Well – when you change the name of your ACS namespace, the name identifiers will change as well and you will will lose your “connection” to your existing users.

Oh an btw – never use any other claims (like email address or name) to form a unique ID – these can often be changed by users.

Saturday, May 21, 2011 4:07:53 PM UTC

I just upload beta 1 to codeplex. Please test this version and give me feedback.

Some quick notes on setup

• Watch the intro screencast on the codeplex site.
• Use the setup tool to set the signing and SSL certificate. You can now also set the ACLs on the private key for your worker pool account.
• IIS is required .
• SSL for the IIS site the STS runs in is required.
• Users of the STS must be in the 'IdentityServerUsers' role.
• Admins of the STS must be in the 'IdentityServerAdministrators' roles.

What’s new?
Mainly smaller bits and pieces and some refactoring. The biggest under the cover change is a new authorization model for the STS itself. If, e.g. you don’t like the new roles I introduced, you can easily change the behavior in the claims authorization manager in the STS web site project.

What’s missing?
The big one is Azure support. Not that I ran into unforeseeable problems here, I just wanted to wait until the on-premise version is more stabilized. Now with B1 I can start adding Azure support back.

Friday, May 20, 2011 2:23:27 PM UTC

It turns out that ACS v2 currently supports two “types” of signing certificates for identity providers:

• self signed certificates
• certificates that chain up to a trusted root (from Microsoft’s perspective), e.g. VeriSign

In other words, when you use a signing certificate in ADFS that comes from your internal PKI, it won’t work.

I hope this will get fixed – err – changed soon.

Thursday, May 12, 2011 12:20:49 PM UTC

I don’t really know what I am talking about here ;) But Jörg does.

http://headwriteline.blogspot.com/2011/05/just-released-thinktecture.html

Tuesday, May 10, 2011 6:47:31 AM UTC

In the previous posts I showed off some of the additions I made to WIF’s authorization infrastructure. I now want to show some samples how I actually use these extensions.

The following code snippets are from Thinktecture.IdentityServer on Codeplex.

The following shows the MVC attribute on the WS-Federation controller:

[ClaimsAuthorize(Constants.Actions.Issue, Constants.Resources.WSFederation)]
public class WSFederationController : Controller

or…

[ClaimsAuthorize(Constants.Actions.Administration, Constants.Resources.RelyingParty)]
public class RelyingPartiesAdminController : Controller

In other places I used the imperative approach (e.g. the WRAP endpoint):

if (!ClaimsAuthorize.CheckAccess(principal, Constants.Actions.Issue, Constants.Resources.WRAP))
{
    Tracing.Error("User not authorized");
    return new UnauthorizedResult("WRAP", true);
}

For the WCF WS-Trust endpoints I decided to use the per-request approach since the SOAP actions are well defined here. The corresponding authorization manager roughly looks like this:

public class AuthorizationManager : ClaimsAuthorizationManager
{
    public override bool CheckAccess(AuthorizationContext context)
    {
        var action = context.Action.First();
        var id = context.Principal.Identities.First();

        // if application authorization request
        if (action.ClaimType.Equals(ClaimsAuthorize.ActionType))
        {
            return AuthorizeCore(action, context.Resource, context.Principal.Identity as IClaimsIdentity);
        }

        // if ws-trust issue request
        if (action.Value.Equals(WSTrust13Constants.Actions.Issue))
        {
            return AuthorizeTokenIssuance(new Collection<Claim>
              { new Claim(ClaimsAuthorize.ResourceType, Constants.Resources.WSTrust) }, id);
        }

        return base.CheckAccess(context);
    }
}

You see that it is really easy now to distinguish between per-request and application authorization which makes the overall design much easier.

HTH

Wednesday, May 04, 2011 1:23:21 PM UTC

In the last post I showed you how to take control over the invocation of ClaimsAuthorizationManager. Then you have complete freedom over the claim types, the amount of claims and the values.

In addition I added two attributes that invoke the authorization manager using an “application claim type”. This way it is very easy to distinguish between authorization calls that originate from WIF’s per-request authorization and the ones from “within” you application.

The attribute comes in two flavours: a CAS attribute (invoked by the CLR) and an ASP.NET MVC attribute (for MVC controllers, invoke by the MVC plumbing). Both also feature static methods to easily call them using the application claim types.

The CAS attribute is part of Thinktecture.IdentityModel on Codeplex (or via NuGet: Install-Package Thinktecture.IdentityModel). If you really want to see that code ;) There is also a sample included in the Codeplex donwload.

The MVC attribute is currently used in Thinktecture.IdentityServer – and I don’t currently plan to make it part of the library project since I don’t want to add a dependency on MVC for now.

You can find the code below – and I will write about its usage in a follow-up post.

public class ClaimsAuthorize : AuthorizeAttribute
{
    private string _resource;
    private string _action;
    private string[] _additionalResources;

    /// <summary>
    /// Default action claim type.
    /// </summary>
    public const string ActionType = "http://application/claims/authorization/action";


    /// <summary>
    /// Default resource claim type
    /// </summary>
    public const string ResourceType = "http://application/claims/authorization/resource";

    /// <summary>
    /// Additional resource claim type
    /// </summary>
    public const string AdditionalResourceType = "http://application/claims/authorization/additionalresource"

    public ClaimsAuthorize(string action, string resource, params string[] additionalResources)
    {
        _action = action;
        _resource = resource;
        _additionalResources = additionalResources;
    }

    public static bool CheckAccess(
      string action, string resource, params string[] additionalResources)
    {
        return CheckAccess(
            Thread.CurrentPrincipal as IClaimsPrincipal,
            action,
            resource,
            additionalResources);
    }

    public static bool CheckAccess(
      IClaimsPrincipal principal, string action, string resource, params string[] additionalResources)
    {
        var context = CreateAuthorizationContext(
            principal,
            action,
            resource,
            additionalResources);

        return ClaimsAuthorization.CheckAccess(context);
    }

    protected override bool AuthorizeCore(HttpContextBase httpContext)
    {
        return CheckAccess(_action, _resource, _additionalResources);
    }

    private static WIF.AuthorizationContext CreateAuthorizationContext(
      IClaimsPrincipal principal, string action, string resource, params string[] additionalResources)
    {
        var actionClaims = new Collection<Claim>
        {
            new Claim(ActionType, action)
        };

        var resourceClaims = new Collection<Claim>
        {
            new Claim(ResourceType, resource)
        };

        if (additionalResources != null && additionalResources.Length > 0)
        {
            additionalResources.ToList().ForEach(ar => resourceClaims.Add(
              new Claim(AdditionalResourceType, ar)));
        }

        return new WIF.AuthorizationContext(
            principal,
            resourceClaims,
            actionClaims);
    }
}

Wednesday, May 04, 2011 10:05:20 AM UTC

As mentioned in my last post, I made several additions to WIF’s built-in authorization infrastructure to make it more flexible and easy to use.

The foundation for all this work is that you have to be able to directly call the registered ClaimsAuthorizationManager. The following snippet is the universal way to get to the WIF configuration that is currently in effect:

public static ServiceConfiguration ServiceConfiguration
{
    get
    {
        if (OperationContext.Current == null)
        {
            // no WCF
            return FederatedAuthentication.ServiceConfiguration;
        }

        // search message property
        if (OperationContext.Current.IncomingMessageProperties.
          ContainsKey("ServiceConfiguration"))
        {
            var configuration = OperationContext.Current.
              IncomingMessageProperties["ServiceConfiguration"] as ServiceConfiguration;

            if (configuration != null)
            {
                return configuration;
            }
        }

        // return configuration from configuration file
        return new ServiceConfiguration();
    }
}

From here you can grab ServiceConfiguration.ClaimsAuthoriationManager which give you direct access to the CheckAccess method (and thus control over claim types and values).

I then created the following wrapper methods:

public static bool CheckAccess(string resource, string action)
{
    return CheckAccess(resource, action, Thread.CurrentPrincipal as IClaimsPrincipal);
}


public static bool CheckAccess(string resource, string action, IClaimsPrincipal principal)
{
    var context = new AuthorizationContext(principal, resource, action);

    return AuthorizationManager.CheckAccess(context);
}

public static bool CheckAccess(Collection<Claim> actions, Collection<Claim> resources)
{
    return CheckAccess(new AuthorizationContext(
        Thread.CurrentPrincipal.AsClaimsPrincipal(), resources, actions));
}

public static bool CheckAccess(AuthorizationContext context)
{
    return AuthorizationManager.CheckAccess(context);
}

I also created the same set of methods but called DemandAccess. They internally use CheckAccess and will throw a SecurityException when false is returned.

All the code is part of Thinktecture.IdentityModel on Codeplex – or via NuGet (Install-Package Thinktecture.IdentityModel).

Tuesday, May 03, 2011 8:55:20 AM UTC

In my last post I wrote about what I like about WIF’s proposed approach to authorization – I also said that I definitely would build upon that infrastructure for my own systems. But implementing such a system is a little harder as it could be. Here’s why (and that’s purely my perspective):

First of all WIF’s authorization comes in two “modes”

• Per-request authorization.
  When an ASP.NET/WCF request comes in, the registered authorization manager gets called. For SOAP the SOAP action gets passed in. For HTTP requests (ASP.NET, WCF REST) the URL and verb.
• Imperative authorization
  This happens when you explicitly call the claims authorization API from within your code. There you have full control over the values for action and resource.

In ASP.NET per-request authorization is optional (depends on if you have added the ClaimsAuthorizationHttpModule). In WCF you always get the per-request checks as soon as you register the authorization manager in configuration.

I personally prefer the imperative authorization because first of all I don’t believe in URL based authorization. Especially in the times of MVC and routing tables, URLs can be easily changed – but then you also have to adjust your authorization logic every time. Also – you typically need more knowledge than a simple “if user x is allowed to invoke operation x”.

One problem I have is, both the per-request calls as well as the standard WIF imperative authorization APIs wrap actions and resources in the same claim type. This makes it hard to distinguish between the two authorization modes in your authorization manager. But you typically need that feature to structure your authorization policy evaluation in a clean way.

The second problem (which is somehow related to the first one) is the standard API for interacting with the claims authorization manager. The API comes as an attribute (ClaimsPrincipalPermissionAttribute) as well as a class to use programmatically (ClaimsPrincipalPermission). Both only allow to pass in simple strings (which results in the wrapping with standard claim types mentioned earlier). Both throw a SecurityException when the check fails.

The attribute is a code access permission attribute (like PrincipalPermission). That means it will always be invoked regardless how you call the code. This may be exactly what you want, or not. In a unit testing situation (like an MVC controller) you typically want to test the logic in the function – not the security check.

The good news is, the WIF API is flexible enough that you can build your own infrastructure around their core. For my own projects I implemented the following extensions:

• A way to invoke the registered claims authorization manager with more overloads, e.g. with different claim types or a complete AuthorizationContext.
• A new CAS attribute (with the same calling semantics as the built-in one) with custom claim types.
• A MVC authorization attribute with custom claim types.
• A way to use branching – as opposed to catching a SecurityException.

I will post the code for these various extensions here – so stay tuned.

Saturday, April 30, 2011 6:45:09 AM UTC

In “traditional” .NET with its IPrincipal interface and IsInRole method, developers were encouraged to write code like this:

In code reviews I’ve seen tons of code like this. What I don’t like about this is, that two concerns in your application get tightly coupled: business and security logic.

But what happens when the security requirements change – and they will (e.g. members of the sales role and some other people from different roles need to create customers)? Well – since your security logic is sprinkled across your project you need to change the security checks in all relevant places (and make sure you don’t forget one) and you need to re-test, re-stage and re-deploy the complete app. This is clearly not what we want.

WIF’s claims-based authorization encourages developers to separate business code and authorization policy evaluation. This is a good thing. So the same security check with WIF’s out-of-the box APIs would look like this:

You notice the fundamental difference? The security check only describes what the code is doing (represented by a resource/action pair) – and does not state who is allowed to invoke the code. As I mentioned earlier – the who is most probably changing over time – the what most probably not.

The call to ClaimsPrincipalPermission hands off to another class called the ClaimsAuthorizationManager. This class handles the evaluation of your security policy and is ideally in a separate assembly to allow updating the security logic independently from the application logic (and vice versa).

The claims authorization manager features a method called CheckAccess that retrieves three values (wrapped inside an AuthorizationContext instance) – action (“add”), resource (“customer”) and the principal (including its claims) in question. CheckAccess then evaluates those three values and returns true/false.

I really like the separation of concerns part here. Unfortunately there is not much support from Microsoft beyond that point. And without further tooling and abstractions the CheckAccess method quickly becomes *very* complex. But still I think that is the way to go.

In the next post I will tell you what I don’t like about it (and how to fix it).

Saturday, April 30, 2011 5:40:00 AM UTC

Der zweite Schwung Videos von meinem Besuch bei Microsoft in München ist nun auch fertig.

Teil 1 - Historie, symmetrische Kryptografie und Hashing
(http://channel9.msdn.com/Blogs/Lori/Kryptografie-Teil-1)

Teil 2 – asymmetrische Krypografie, X.509 Zertifikate, PKCS und SSL
(http://channel9.msdn.com/Blogs/Lori/Kryptografie-Teil-2)

Wednesday, April 27, 2011 7:59:46 PM UTC

I haven’t been blogging about ACS2 in the past because it was not released and I was kinda busy with other stuff. Needless to say I spent quite some time with ACS2 already (both in customer situations as well as in the classroom and at conferences).

ACS2 rocks! It’s IMHO the most interesting and useful (and most unique) part of the whole Azure offering!

For my talk at VSLive yesterday, I played a little with the Facebook integration. See Steve’s post on the general setup.

One claim that you get back from Facebook is an access token. This token can be used to directly talk to Facebook and query additional properties about the user. Which properties you have access to depends on which authorization your Facebook app requests. You can specify this in the identity provider registration page for Facebook in ACS2. In my example I added access to the home town property of the user.

Once you have the access token from ACS you can use e.g. the Facebook SDK from Codeplex (also available via NuGet) to talk to the Facebook API.

In my sample I used the WIF ClaimsAuthenticationManager to add the additional home town claim. This is not necessarily how you would do it in a “real” app. Depends ;)

The code looks like this (sample code!):

public class ClaimsTransformer : ClaimsAuthenticationManager
{
    public override IClaimsPrincipal Authenticate(
      string resourceName, IClaimsPrincipal incomingPrincipal)
    {
        if (!incomingPrincipal.Identity.IsAuthenticated)
        {
            return base.Authenticate(resourceName, incomingPrincipal);
        }

        string accessToken;
        if (incomingPrincipal.TryGetClaimValue(
          "http://www.facebook.com/claims/AccessToken", out accessToken))
        {
            try
            {
                var home = GetFacebookHometown(accessToken);
                if (!string.IsNullOrWhiteSpace(home))
                {
                    incomingPrincipal.Identities[0].Claims.Add(
                      new Claim("http://www.facebook.com/claims/HomeTown", home));
                }
            }
            catch { }
        }

        return incomingPrincipal;
    }

     private string GetFacebookHometown(string token)
    {
        var client = new FacebookClient(token);
        dynamic parameters = new ExpandoObject();
        parameters.fields = "hometown";
        dynamic result = client.Get("me", parameters);

        return result.hometown.name;
    }
}

Friday, April 22, 2011 3:12:03 PM UTC

All the videos from the excellent Örebro event are now online.

• Dominick Baier: A Technical Introduction to the Windows Identity Foundation (watch)
• Dominick Baier & Christian Weyer: Securing REST-Services and Web APIs on the Windows Azure Platform (watch)
• Christian Weyer: Real World Azure - Elasticity from on-premise to the cloud and back (watch)
• Our interview with Robert (watch)

Sunday, April 17, 2011 7:18:02 AM UTC

I uploaded a small refresh of IdentityServer to Codeplex.

Mostly bug fixes and an experimental OAuth 2 (WRAP) endpoint. I also included a sample RP to go along.

Monday, April 11, 2011 11:29:47 AM UTC

When using Robocopy to backup data to a NAS, I always had the problem that most files were considered “old” on the NAS device (even if they weren’t) – that kind of defeats the purpose of the /MIR switch.

Today I finally decided to search for a solution – and it was remarkably easy. Most NAS devices use Samba or something similar to provide “NTFS shares” – but most of them only implement FAT-style file times with a 2-second-granularity.

You can force robocopy to use FAT file time as well using the /FFT switch. Now my backup script works again as expected.

See also here.

Monday, April 11, 2011 11:27:20 AM UTC

Ich habe vor ein paar Wochen mit Lori drei Videos zum Thema Windows Security für Entwickler aufgenommen – die sind nun Online.

Der erste Teil beschäftigt sich mit den absoluten Grundlagen der Windows Sicherheit. Was ist ein Konto? Was ist eine SID? Was ist ein Windows Token? Weiterhin wird gezeigt, wie sich diese grundlegenden Windows Einrichtungen über Managed Code anprogrammieren lassen. Der Vortrag endet mit einem kleinen Einblick in die Vorgehensweise von UAC, und wie dieses programmatisch verwendet werden kann.
http://channel9.msdn.com/Blogs/Lori/Windows-Security-fr-Developers-Teil-1

Teil zwei beschäfitgt sich mit Zugriffs-Kontrolllisten, und wie diese mit .NET Code gelesen und geschrieben werden können. Weiterhin werden die beiden verwandten Konzepte Logon Session und Impersonierung besprochen. Beide Einrichtungen erzeugen einen neuen Token, sind aber grundlegend verschieden in ihren Einsatzgebieten.
http://channel9.msdn.com/Blogs/Lori/Windows-Security-fr-Developers-Teil-2

Teil drei stellt das Kerberos Netzwerk-Authentifizierungsprotokoll vor. Da dieses Protokoll standardmäßig in Active Directory verwendet wird, sollten man es in den Grundzügen kennen. Natürlich kann auch Kerberos aus Managed Code verwendet werden – die abschließende Demo zeigt wie dies funktioniert.
http://channel9.msdn.com/Blogs/Lori/Windows-Security-fr-Developers-Teil-3

…und noch ein kleines Interview
http://channel9.msdn.com/Blogs/Lori/Interview-mit-Dominick-Baier

Viel Spaß ;)

Wednesday, April 06, 2011 2:11:12 PM UTC

We had a really good time in Sweden. Thanks for Microsoft and the organizers/staff!

Robert did a short interview with Christian and me. Enjoy ;)

http://www.youtube.com/watch?v=cGFaX_2GIPw

Friday, April 01, 2011 10:07:10 AM UTC

I just uploaded the very first CTP1 of thinktecture IdentityServer to codeplex. I wanted to make this code available to gather feedback and extended review. Keep in mind it is not done yet.

I also recorded an intro screencast that briefly walks through the new codebase.

Have fun!

Friday, April 01, 2011 6:56:06 AM UTC

The source code for StarterSTS 1.5 can be found here.

The new Codeplex space is http://identityserver.codeplex.com (not published yet).

Friday, March 11, 2011 10:45:21 AM UTC

I have the 1.5 version of StarterSTS sitting here for quite some time now. But I was always reluctant to release it. Some of the reasons are:

• too many new features for a single (small) version change.
• to many features that are optional, like bridged authentication and thus make the code very complex.
• the way I implemented Azure integration adds a dependency on the Azure SDK, even for “on-premise” installations. I don’t like that.
• the fact I am using some WebForms bits and some WCF bits, the URL structure got messy. WebForms also don’t help a lot in testability

All of the above reasons together plus the fact that I am the only architect, developer and tester on this project made me come to the conclusion that I will cancel this release. But wait…

• StarterSTS 1.5 is fully functional. We use both the on-premise and Azure versions internally “in production”.
• Cancelling means I will release the latest source code on Codeplex – but will not mark it as a “recommended release”. I also won’t produce updated screen casts and docs. Bu the setup is very similar to earlier versions.
• Feel free to use and customize 1.5 and give me feedback.

On the good news front, I am working on a new version – welcome thinktecture IdentityServer. This version is based on MVC3 and the routing architecture, removed a lot of the clutter, has a SQL CE4 based configuration system, is more extensible – and in overall just cleaner.

I will be able to upload CTPs very soon.

Friday, March 11, 2011 9:17:00 AM UTC

This can come in handy when troubleshooting:

using System;

using System.Diagnostics;

using System.Text;

namespace Thinktecture.Azure

{

    class Program

    {

        static EventLog _eventLog = new EventLog("Application", ".", "StartupTaskShell");

        static StringBuilder _out = new StringBuilder(64);

        static StringBuilder _err = new StringBuilder(64);

        static int Main(string[] args)

        {

            if (args.Length != 1)

            {

                Console.WriteLine("Invalid arguments: " + String.Join(", ", args));

                _eventLog.WriteEntry("Invalid arguments: " + String.Join(", ", args));

                return -1;

            }

            var task = args[0];

            ProcessStartInfo info = new ProcessStartInfo()

            {

                FileName = task,

                WorkingDirectory = Environment.CurrentDirectory,

                UseShellExecute = false,

                ErrorDialog = false,

                CreateNoWindow = true,

                RedirectStandardOutput = true,

                RedirectStandardError = true

            };

            var process = new Process();

            process.StartInfo = info;

            process.OutputDataReceived += (s, e) =>

                {

                    if (e.Data != null)

                    {

                        _out.AppendLine(e.Data);

                    }

                };

            process.ErrorDataReceived += (s, e) =>

                {

                    if (e.Data != null)

                    {

                        _err.AppendLine(e.Data);

                    }

                };

            process.Start();

            process.BeginOutputReadLine();

            process.BeginErrorReadLine();

            process.WaitForExit();

            var outString = _out.ToString();

            var errString = _err.ToString();

            if (!string.IsNullOrWhiteSpace(outString))

            {

                outString = String.Format("Standard Out for {0}\n\n{1}", task, outString);

                _eventLog.WriteEntry(outString, EventLogEntryType.Information);

            }

            if (!string.IsNullOrWhiteSpace(errString))

            {

                errString = String.Format("Standard Err for {0}\n\n{1}", task, errString);

                _eventLog.WriteEntry(errString, EventLogEntryType.Error);

            }

            return 0;

        }

    }

You then wrap your startup tasks with the StartupTaskShell and you’ll be able to see stdout and stderr in the application event log.

Friday, March 04, 2011 9:24:44 AM UTC

The title says it all ;)

certutil -addstore root LeastPrivilegeCA.cer

Tuesday, March 01, 2011 2:25:16 PM UTC

A question that I often hear these days is: “Can I connect a Windows Phone 7 device to my existing enterprise services?”.

Well – since most of my services are typically issued token based, this requires support for WS-Trust and WS-Security on the client. Let’s see what’s necessary to write a WP7 client for this scenario.

First I converted the Silverlight library that comes with the Identity Training Kit to WP7. Some things are not supported in WP7 WCF (like message inspectors and some client runtime hooks) – but besides that this was a simple copy+paste job. Very nice!

Next I used the WSTrustClient to request tokens from my STS:

private WSTrustClient GetWSTrustClient()
{
    var client = new WSTrustClient(
        new WSTrustBindingUsernameMixed(),
        new EndpointAddress("https://identity.thinktecture.com/…/issue.svc/mixed/username"),
        new UsernameCredentials(_txtUserName.Text, _txtPassword.Password));
    return client;
}

private void _btnLogin_Click(object sender, RoutedEventArgs e)
{
    _client = GetWSTrustClient();

    var rst = new RequestSecurityToken(WSTrust13Constants.KeyTypes.Bearer)
    {
        AppliesTo = new EndpointAddress("https://identity.thinktecture.com/rp/")
    };

    _client.IssueCompleted += client_IssueCompleted;
    _client.IssueAsync(rst);
}

I then used the returned RSTR to talk to the WCF service.

Due to a bug in the combination of the Silverlight library and the WP7 runtime – symmetric key tokens seem to have issues currently. Bearer tokens work fine. So I created the following binding for the WCF endpoint specifically for WP7.

<customBinding>


  <binding name="mixedNoSessionBearerBinary">
    <security authenticationMode="IssuedTokenOverTransport"
              messageSecurityVersion="WSSecurity11
                                      WSTrust13
                                      WSSecureConversation13
                                      WSSecurityPolicy12
                                      BasicSecurityProfile10">
      <issuedTokenParameters keyType="BearerKey" />
    </security>
    <binaryMessageEncoding />
    <httpsTransport/>
  </binding>
</customBinding>

The binary encoding is not necessary, but will speed things up a little for mobile devices.

I then call the service with the following code:

private void _btnCallService_Click(object sender, RoutedEventArgs e)

{

    var binding = new CustomBinding(

        new BinaryMessageEncodingBindingElement(),

        new HttpsTransportBindingElement());

    _proxy = new StarterServiceContractClient(

        binding,

        new EndpointAddress("…"));

    using (var scope = new OperationContextScope(_proxy.InnerChannel))

    {

        OperationContext.Current.OutgoingMessageHeaders.Add(new IssuedTokenHeader(Globals.RSTR));

        _proxy.GetClaimsAsync();

    }

works.

download

Friday, February 25, 2011 8:35:12 AM UTC

http://blogs.msdn.com/b/card/archive/2011/02/15/beyond-windows-cardspace.aspx

Tuesday, February 15, 2011 5:51:15 PM UTC

Grats to Nick for the biggest DevWeek ever! Looking forward to it!

Monday, January 31, 2011 7:12:36 AM UTC

http://www.troopers.de/

‘nuff said – be there ;)

Wednesday, January 26, 2011 6:10:58 AM UTC

You can add my WIF helper library now via NuGet.

Simply type “Install-Package Thinktecture.IdentityModel” into the Package Manager Console. Or use the “Add Library Package Reference” dialog.

Friday, January 21, 2011 10:56:47 AM UTC

…and will be released soon ;)

Monday, January 10, 2011 9:16:21 PM UTC

I ran into some problems while trying to make SSL client certificates work for StarterSTS 1.5. In theory you have to do two things (via startup tasks):

• Unlock the SSL section in IIS
• Install all the root certificates for the client certs you want to accept

I did that. But it still does not work. While inspecting the event log, I stumbled over an schannel error message that I’ve never seen before:

“When asking for client authentication, this server sends a list of trusted certificate authorities to the client. The client uses this list to choose a client certificate that is trusted by the server. Currently, this server trusts so many certificate authorities that the list has grown too long. This list has thus been truncated. The administrator of this machine should review the certificate authorities trusted for client authentication and remove those that do not really need to be trusted.”

WTF? And indeed standard Azure (web role) VMs trust 275 root CAs (see attached list). Including kinda obscure ones. I don’t really know why MS made this design decision. It seems just wrong (including breaking the SSL client cert functionality).

Deleting like 60% of them made SSL client certs from my CA work. So I guess I now have to find an automated way to attach CTLs to my site…joy.

Exported list of trusted CA (as of 30th Dec 2010)
AC Raíz Certicámara S.A. (4/2/2030 9:42:02 PM)
AC RAIZ FNMT-RCM (1/1/2030 12:00:00 AM)
A-CERT ADVANCED (10/23/2011 2:14:14 PM)
Actalis Authentication CA G1 (6/25/2022 2:06:00 PM)
Agence Nationale de Certification Electronique (8/12/2037 9:03:17 AM)
Agence Nationale de Certification Electronique (8/12/2037 9:58:14 AM)
Agencia Catalana de Certificacio (NIF Q-0801176-I) (1/7/2031 10:59:59 PM)
America Online Root Certification Authority 1 (11/19/2037 8:43:00 PM)
America Online Root Certification Authority 2 (9/29/2037 2:08:00 PM)
ANCERT Certificados CGN (2/11/2024 5:27:12 PM)
ANCERT Certificados Notariales (2/11/2024 3:58:26 PM)
ANCERT Corporaciones de Derecho Publico (2/11/2024 5:22:45 PM)
A-Trust-nQual-01 (11/30/2014 11:00:00 PM)
A-Trust-nQual-03 (8/17/2015 10:00:00 PM)
A-Trust-Qual-01 (11/30/2014 11:00:00 PM)
A-Trust-Qual-02 (12/2/2014 11:00:00 PM)
A-Trust-Qual-03a (4/24/2018 10:00:00 PM)
Austria Telekom-Control Kommission (9/24/2005 12:40:00 PM)
Austrian Society for Data Protection (2/12/2009 11:30:30 AM)
Austrian Society for Data Protection GLOBALTRUST Certification Service (9/18/2036 2:12:35 PM)
Autoridad Certificadora Raiz de la Secretaria de Economia (5/9/2025 12:00:00 AM)
Autoridad de Certificacion de la Abogacia (6/13/2030 10:00:00 PM)
Autoridad de Certificacion Firmaprofesional CIF A62634068 (10/24/2013 10:00:00 PM)
Autoridade Certificadora Raiz Brasileira (11/30/2011 11:59:00 PM)
Baltimore CyberTrust Root (5/12/2025 11:59:00 PM)
BIT AdminCA-CD-T01 (1/25/2016 12:36:19 PM)
BIT Admin-Root-CA (11/10/2021 7:51:07 AM)
Buypass Class 2 CA 1 (10/13/2016 10:25:09 AM)
Buypass Class 3 CA 1 (5/9/2015 2:13:03 PM)
CA Disig (3/22/2016 1:39:34 AM)
CertEurope (3/27/2037 11:00:00 PM)
CERTICAMARA S.A. (2/23/2015 5:10:37 PM)
Certicámara S.A. (5/23/2011 10:00:00 PM)
Certigna (6/29/2027 3:13:05 PM)
Certipost E-Trust Primary Normalised CA (7/26/2020 10:00:00 AM)
Certipost E-Trust Primary Qualified CA (7/26/2020 10:00:00 AM)
Certipost E-Trust Primary TOP Root CA (7/26/2025 10:00:00 AM)
Certisign Autoridade Certificadora AC1S (6/27/2018 12:00:00 AM)
Certisign Autoridade Certificadora AC2 (6/27/2018 12:00:00 AM)
Certisign Autoridade Certificadora AC3S (7/9/2018 8:56:32 PM)
Certisign Autoridade Certificadora AC4 (6/27/2018 12:00:00 AM)
CertPlus Class 1 Primary CA (7/6/2020 11:59:59 PM)
CertPlus Class 2 Primary CA (7/6/2019 11:59:59 PM)
CertPlus Class 3 Primary CA (7/6/2019 11:59:59 PM)
CertPlus Class 3P Primary CA (7/6/2019 11:59:59 PM)
CertPlus Class 3TS Primary CA (7/6/2019 11:59:59 PM)
CertRSA01 (3/3/2010 2:59:59 PM)
certSIGN Root CA (7/4/2031 5:20:04 PM)
Certum (6/11/2027 10:46:39 AM)
Certum Trusted Network CA (12/31/2029 12:07:37 PM)
Chambers of Commerce Root - 2008 (7/31/2038 12:29:50 PM)
Chambersign Chambers of Commerce Root (9/30/2037 4:13:44 PM)
Chambersign Global Root (9/30/2037 4:14:18 PM)
Chambersign Public Notary Root (9/30/2037 4:14:49 PM)
Chunghwa Telecom Co. Ltd. (12/20/2034 2:31:27 AM)
Cisco Systems (5/14/2029 8:25:42 PM)
CNNIC Root (4/16/2027 7:09:14 AM)
Common Policy (10/15/2027 4:08:00 PM)
COMODO (12/31/2028 11:59:59 PM)
COMODO (1/18/2038 11:59:59 PM)
COMODO (12/31/2029 11:59:59 PM)
ComSign Advanced Security CA (3/24/2029 9:55:55 PM)
ComSign CA (3/19/2029 3:02:18 PM)
ComSign Secured CA (3/16/2029 3:04:56 PM)
Correo Uruguayo - Root CA (12/31/2030 2:59:59 AM)
Cybertrust Global Root (12/15/2021 8:00:00 AM)
DanID (2/11/2037 9:09:30 AM)
DanID (4/5/2021 5:03:17 PM)
Deutsche Telekom Root CA 2 (7/9/2019 11:59:00 PM)
DigiCert (11/10/2031 12:00:00 AM)
DigiCert (11/10/2031 12:00:00 AM)
DigiCert (11/10/2031 12:00:00 AM)
DigiNotar Root CA (3/31/2025 6:19:21 PM)
DIRECCION GENERAL DE LA POLICIA (2/8/2036 10:59:59 PM)
DST (ABA.ECOM) CA (7/9/2009 5:33:53 PM)
DST (ANX Network) CA (12/9/2018 4:16:48 PM)
DST (Baltimore EZ) CA (7/3/2009 7:56:53 PM)
DST (National Retail Federation) RootCA (12/8/2008 4:14:16 PM)
DST (United Parcel Service) RootCA (12/7/2008 12:25:46 AM)
DST ACES CA X6 (11/20/2017 9:19:58 PM)
DST Root CA X3 (9/30/2021 2:01:15 PM)
DST RootCA X1 (11/28/2008 6:18:55 PM)
DST RootCA X2 (11/27/2008 10:46:16 PM)
DSTCA E1 (12/10/2018 6:40:23 PM)
DSTCA E2 (12/9/2018 7:47:26 PM)
DST-Entrust GTI CA (12/9/2018 12:32:24 AM)
D-TRUST GmbH (5/16/2022 5:20:47 AM)
D-TRUST GmbH (6/8/2012 11:47:46 AM)
D-TRUST GmbH (5/16/2022 5:20:47 AM)
EBG Elektronik Sertifika Hizmet Saglayicisi (8/14/2016 12:31:09 AM)
E-Certchile (9/5/2028 7:39:41 PM)
Echoworx Root CA2 (10/7/2030 10:49:13 AM)
ECRaizEstado (6/23/2030 1:41:27 PM)
EDICOM (4/13/2028 4:24:22 PM)
E-GÜVEN Elektronik Sertifika Hizmet Saglayicisi (1/4/2017 11:32:48 AM)
E-ME SSI (RCA) (5/19/2027 8:48:15 AM)
Entrust (11/27/2026 8:53:42 PM)
Entrust (5/25/2019 4:39:40 PM)
Entrust.net (12/7/2030 5:55:54 PM)
Equifax Secure eBusiness CA-1 (6/21/2020 4:00:00 AM)
Equifax Secure eBusiness CA-2 (6/23/2019 12:14:45 PM)
Equifax Secure Global eBusiness CA-1 (6/21/2020 4:00:00 AM)
eSign Australia: eSign Imperito Primary Root CA (5/23/2012 11:59:59 PM)
eSign Australia: Gatekeeper Root CA (5/23/2014 11:59:59 PM)
eSign Australia: Primary Utility Root CA (5/23/2012 11:59:59 PM)
Fabrica Nacional de Moneda y Timbre (3/18/2019 3:26:19 PM)
GeoTrust (8/22/2018 4:41:51 PM)
GeoTrust (7/16/2036 11:59:59 PM)
GeoTrust Global CA (5/21/2022 4:00:00 AM)
GeoTrust Global CA 2 (3/4/2019 5:00:00 AM)
GeoTrust Primary Certification Authority - G2 (1/18/2038 11:59:59 PM)
GeoTrust Primary Certification Authority - G3 (12/1/2037 11:59:59 PM)
GeoTrust Universal CA (3/4/2029 5:00:00 AM)
GeoTrust Universal CA 2 (3/4/2029 5:00:00 AM)
Global Chambersign Root - 2008 (7/31/2038 12:31:40 PM)
GlobalSign (1/28/2028 12:00:00 PM)
GlobalSign (12/15/2021 8:00:00 AM)
Go Daddy Class 2 Certification Authority (6/29/2034 5:06:20 PM)
GTE CyberTrust Global Root (8/13/2018 11:59:00 PM)
GTE CyberTrust Root (4/3/2004 11:59:00 PM)
GTE CyberTrust Root (2/23/2006 11:59:00 PM)
Halcom CA FO (6/5/2020 10:33:31 AM)
Halcom CA PO 2 (2/7/2019 6:33:31 PM)
Hongkong Post Root CA (1/16/2010 11:59:00 PM)
Hongkong Post Root CA 1 (5/15/2023 4:52:29 AM)
I.CA První certifikacní autorita a.s. (4/1/2018 12:00:00 AM)
I.CA První certifikacní autorita a.s. (4/1/2018 12:00:00 AM)
InfoNotary (3/6/2026 5:33:05 PM)
IPS SERVIDORES (12/29/2009 11:21:07 PM)
IZENPE S.A. (1/30/2018 11:00:00 PM)
Izenpe.com (12/13/2037 8:27:25 AM)
Japan Certification Services, Inc. SecureSign RootCA1 (9/15/2020 2:59:59 PM)
Japan Certification Services, Inc. SecureSign RootCA11 (4/8/2029 4:56:47 AM)
Japan Certification Services, Inc. SecureSign RootCA2 (9/15/2020 2:59:59 PM)
Japan Certification Services, Inc. SecureSign RootCA3 (9/15/2020 2:59:59 PM)
Japan Local Government PKI Application CA (3/31/2016 2:59:59 PM)
Japanese Government ApplicationCA (12/12/2017 3:00:00 PM)
Juur-SK AS Sertifitseerimiskeskus (8/26/2016 2:23:01 PM)
KamuSM (8/21/2017 11:37:07 AM)
KISA RootCA 1 (8/24/2025 8:05:46 AM)
KISA RootCA 3 (11/19/2014 6:39:51 AM)
Macao Post eSignTrust (1/29/2013 11:59:59 PM)
MicroSec e-Szigno Root CA (4/6/2017 12:28:44 PM)
Microsoft Authenticode(tm) Root (12/31/1999 11:59:59 PM)
Microsoft Root Authority (12/31/2020 7:00:00 AM)
Microsoft Root Certificate Authority (5/9/2021 11:28:13 PM)
Microsoft Timestamp Root (12/30/1999 11:59:59 PM)
MOGAHA Govt of Korea (4/21/2012 9:07:23 AM)
MOGAHA Govt of Korea GPKI (3/15/2017 6:00:04 AM)
NetLock Arany (Class Gold) Fotanúsítvány (12/6/2028 3:08:21 PM)
NetLock Expressz (Class C) Tanusitvanykiado (2/20/2019 2:08:11 PM)
NetLock Kozjegyzoi (Class A) Tanusitvanykiado (2/19/2019 11:14:47 PM)
NetLock Minositett Kozjegyzoi (Class QA) Tanusitvanykiado (12/15/2022 1:47:11 AM)
NetLock Platina (Class Platinum) Fotanúsítvány (12/6/2028 3:12:44 PM)
NetLock Uzleti (Class B) Tanusitvanykiado (2/20/2019 2:10:22 PM)
Netrust CA1 (3/30/2021 2:57:45 AM)
Network Solutions (12/31/2029 11:59:59 PM)
NLB Nova Ljubljanska Banka d.d. Ljubljana (5/15/2023 12:22:45 PM)
OISTE WISeKey Global Root GA CA (12/11/2037 4:09:51 PM)
Post.Trust Root CA (7/5/2022 9:12:33 AM)
Post.Trust Root CA (8/20/2010 1:56:21 PM)
Posta CA Root (10/20/2028 12:52:08 PM)
POSTarCA (2/7/2023 11:06:58 AM)
QuoVadis Root CA 2 (11/24/2031 6:23:33 PM)
QuoVadis Root CA 3 (11/24/2031 7:06:44 PM)
QuoVadis Root Certification Authority (3/17/2021 6:33:33 PM)
Root CA Generalitat Valenciana (7/1/2021 3:22:47 PM)
RSA Security 2048 V3 (2/22/2026 8:39:23 PM)
SECOM Trust Systems CO LTD (6/6/2037 2:12:32 AM)
SECOM Trust Systems CO LTD (6/25/2019 10:23:48 PM)
SECOM Trust Systems CO LTD (9/30/2023 4:20:49 AM)
Secretaria de Economia Mexico (5/8/2025 12:00:00 AM)
Secrétariat Général de la Défense Nationale (10/17/2020 2:29:22 PM)
SecureNet CA Class B (10/16/2009 9:59:00 AM)
Serasa Certificate Authority I (11/21/2024 2:12:45 PM)
Serasa Certificate Authority II (11/21/2024 12:44:48 PM)
Serasa Certificate Authority III (11/21/2024 1:24:14 PM)
SERVICIOS DE CERTIFICACION - A.N.C. (3/9/2009 9:08:07 PM)
Sigen-CA (6/29/2021 9:57:46 PM)
Sigov-CA (1/10/2021 2:22:52 PM)
Skaitmeninio sertifikavimo centras (12/28/2026 12:05:04 PM)
Skaitmeninio sertifikavimo centras (12/25/2026 12:08:26 PM)
Skaitmeninio sertifikavimo centras (12/22/2026 12:11:30 PM)
Sonera Class1 CA (4/6/2021 10:49:13 AM)
Sonera Class2 CA (4/6/2021 7:29:40 AM)
Spanish Property & Commerce Registry CA (4/27/2012 9:39:50 AM)
Staat der Nederlanden Root CA (12/16/2015 9:15:38 AM)
Staat der Nederlanden Root CA - G2 (3/25/2020 11:03:10 AM)
Starfield Class 2 Certification Authority (6/29/2034 5:39:16 PM)
Starfield Technologies (6/26/2019 12:19:54 AM)
Starfield Technologies Inc. (12/31/2029 11:59:59 PM)
StartCom Certification Authority (9/17/2036 7:46:36 PM)
S-TRUST Authentication and Encryption Root CA 2005:PN (6/21/2030 11:59:59 PM)
Swisscom Root CA 1 (8/18/2025 10:06:20 PM)
SwissSign (10/25/2036 8:30:35 AM)
SwissSign Platinum G2 Root CA (10/25/2036 8:36:00 AM)
SwissSign Silver G2 Root CA (10/25/2036 8:32:46 AM)
TC TrustCenter Class 1 CA (1/1/2011 11:59:59 AM)
TC TrustCenter Class 2 CA (1/1/2011 11:59:59 AM)
TC TrustCenter Class 2 CA II (12/31/2025 10:59:59 PM)
TC TrustCenter Class 3 CA (1/1/2011 11:59:59 AM)
TC TrustCenter Class 3 CA II (12/31/2025 10:59:59 PM)
TC TrustCenter Class 4 CA (1/1/2011 11:59:59 AM)
TC TrustCenter Class 4 CA II (12/31/2025 10:59:59 PM)
TC TrustCenter Time Stamping CA (1/1/2011 11:59:59 AM)
TC TrustCenter Universal CA I (12/31/2025 10:59:59 PM)
TC TrustCenter Universal CA II (12/31/2030 10:59:59 PM)
thawte (12/31/2020 11:59:59 PM)
thawte (7/16/2036 11:59:59 PM)
thawte (12/31/2020 11:59:59 PM)
thawte (12/31/2020 11:59:59 PM)
thawte (12/31/2020 11:59:59 PM)
thawte (12/31/2020 11:59:59 PM)
thawte (12/31/2020 11:59:59 PM)
thawte Primary Root CA - G2 (1/18/2038 11:59:59 PM)
thawte Primary Root CA - G3 (12/1/2037 11:59:59 PM)
Thawte Timestamping CA (12/31/2020 11:59:59 PM)
Trustis EVS Root CA (1/9/2027 11:56:00 AM)
Trustis FPS Root CA (1/21/2024 11:36:54 AM)
Trustwave (1/1/2035 5:37:19 AM)
Trustwave (12/31/2029 7:40:55 PM)
Trustwave (12/31/2029 7:52:06 PM)
TURKTRUST Elektronik Islem Hizmetleri (9/16/2015 12:13:05 PM)
TURKTRUST Elektronik Islem Hizmetleri (3/22/2015 10:04:51 AM)
TURKTRUST Elektronik Sertifika Hizmet Saglayicisi (9/16/2015 10:07:57 AM)
TURKTRUST Elektronik Sertifika Hizmet Saglayicisi (3/22/2015 10:27:17 AM)
TÜRKTRUST Elektronik Sertifika Hizmet Saglayicisi (12/22/2017 6:37:19 PM)
TW Government Root Certification Authority (12/5/2032 1:23:33 PM)
TWCA Root Certification Authority 1 (12/31/2030 3:59:59 PM)
TWCA Root Certification Authority 2 (12/31/2030 3:59:59 PM)
U.S. Government FBCA (10/6/2010 6:53:56 PM)
UCA Global Root (12/31/2037 12:00:00 AM)
UCA Root (12/31/2029 12:00:00 AM)
USERTrust (7/9/2019 6:40:36 PM)
USERTrust (7/9/2019 5:36:58 PM)
USERTrust (6/24/2019 7:06:30 PM)
USERTrust (7/9/2019 6:19:22 PM)
USERTrust (5/30/2020 10:48:38 AM)
UTN - USERFirst-Network Applications (7/9/2019 6:57:49 PM)
ValiCert Class 3 Policy Validation Authority (6/26/2019 12:22:33 AM)
VAS Latvijas Pasts SSI(RCA) (9/13/2024 9:27:57 AM)
VeriSign (5/18/2018 11:59:59 PM)
VeriSign (7/16/2036 11:59:59 PM)
VeriSign (8/1/2028 11:59:59 PM)
VeriSign (12/31/1999 9:37:48 AM)
VeriSign (1/7/2004 11:59:59 PM)
VeriSign (5/18/2018 11:59:59 PM)
VeriSign (1/7/2004 11:59:59 PM)
VeriSign (8/1/2028 11:59:59 PM)
VeriSign (8/1/2028 11:59:59 PM)
VeriSign (1/7/2020 11:59:59 PM)
VeriSign (12/31/1999 9:35:58 AM)
VeriSign (8/1/2028 11:59:59 PM)
VeriSign (7/16/2036 11:59:59 PM)
VeriSign (1/7/2004 11:59:59 PM)
VeriSign (7/16/2036 11:59:59 PM)
VeriSign (1/7/2010 11:59:59 PM)
VeriSign (5/18/2018 11:59:59 PM)
VeriSign (8/1/2028 11:59:59 PM)
VeriSign (1/7/2004 11:59:59 PM)
VeriSign (7/16/2036 11:59:59 PM)
VeriSign (7/16/2036 11:59:59 PM)
VeriSign (8/1/2028 11:59:59 PM)
VeriSign (5/18/2018 11:59:59 PM)
VeriSign Class 3 Public Primary CA (8/1/2028 11:59:59 PM)
VeriSign Class 3 Public Primary Certification Authority - G4 (1/18/2038 11:59:59 PM)
VeriSign Time Stamping CA (1/7/2004 11:59:59 PM)
VeriSign Universal Root Certification Authority (12/1/2037 11:59:59 PM)
Visa eCommerce Root (6/24/2022 12:16:12 AM)
Visa Information Delivery Root CA (6/29/2025 5:42:42 PM)
VRK Gov. Root CA (12/18/2023 1:51:08 PM)
Wells Fargo Root Certificate Authority (1/14/2021 4:41:28 PM)
WellsSecure Public Certificate Authority (12/14/2022 12:07:54 AM)
Xcert EZ by DST (7/11/2009 4:14:18 PM)

Thursday, December 30, 2010 10:21:18 AM UTC

To quote my good friend Christian:

“Tracing is probably one of the most discussed topics in the Windows Azure world. Not because it is freaking cool – but because it can be very tedious and partly massively counter-intuitive.”

<rant>

The .NET Framework has this wonderful facility called TraceSource. You define a named trace and route that to a configurable listener. This gives you a lot of flexibility – you can create a single trace file – or multiple ones. There is even nice tooling around that. SvcTraceViewer from the SDK let’s you open the XML trace files – you can filter and sort by trace source and event type, aggregate multiple files…blablabla. Just what you would expect from a decent tracing infrastructure.

Now comes Windows Azure. I was already very grateful that starting with the SDK 1.2 we finally had a way to do tracing and diagnostics in the cloud (kudos!). But the way the Azure DiagnosticMonitor is currently implemented – could be called flawed.

The Azure SDK provides a DiagnosticsMonitorTraceListener – which is the right way to go. The only problem is, that way this works is, that all traces (from all sources) get written to an ETW trace. Then the DiagMon listens to these traces and copies them periodically to your storage account. So far so good.

But guess what happens to your nice trace files:

• the trace source names get “lost”. They appear in your message text at the end. So much for filtering and sorting and aggregating (regex #fail or #win??).
• Every trace line becomes an entry in an Azure Storage Table – the svclog format is gone. So much for the existing tooling.

To solve that problem, one workaround was to write your own trace listener (!) that creates svclog files inside of local storage and use the DiagMon to copy those. Christian has a blog post about that. OK done that.

Now it turns out that this mechanism does not work anymore in 1.3 with FullIIS (see here). Quoting:

“Some IIS 7.0 logs not collected due to permissions issues...The root cause to both of these issues is the permissions on the log files.”

And the workaround:

“To read the files yourself, log on to the instance with a remote desktop connection.”

Now then have fun with your multi-instance deployments….

So the bottom line is, that currently you cannot copy IIS logs, FREB logs and everything else that gets written by W3WP. Nice…

</rant>

Wednesday, December 29, 2010 11:53:50 AM UTC

Posting the favourite command line snippet seems to be the newest hobby for Azure developers ;)

Here’s one that is useful to unlock the SSL section (e.g. for client certificates):

%windir%\System32\inetsrv\appcmd.exe unlock config /section:system.webServer/security/access

Tuesday, December 28, 2010 8:52:25 PM UTC

While finalizing StarterSTS 1.5, I had a closer look at lifetime and configuration management in Windows Azure.

(this is no new information – just some bits and pieces compiled at one single place – plus a bit of reality check)

When dealing with lifetime management (and especially configuration changes), there are two mechanisms in Windows Azure – a RoleEntryPoint derived class and a couple of events on the RoleEnvironment class. You can find good documentation about RoleEntryPoint here. The RoleEnvironment class features two events that deal with configuration changes – Changing and Changed.

Whenever a configuration change gets pushed out by the fabric controller (either changes in the settings section or the instance count of a role) the Changing event fires. The event handler receives an instance of the RoleEnvironmentChangingEventArgs type. This contains a collection of type RoleEnvironmentChange. This in turn is a base class for two other classes that detail the two types of possible configuration changes I mentioned above: RoleEnvironmentConfigurationSettingsChange (configuration settings) and RoleEnvironmentTopologyChange (instance count). The two respective classes contain information about which configuration setting and which role has been changed. Furthermore the Changing event can trigger a role recycle (aka reboot) by setting EventArgs.Cancel to true.

So your typical job in the Changing event handler is to figure if your application can handle these configuration changes at runtime, or if you rather want a clean restart. Prior to the SDK 1.3 VS Templates – the following code was generated to reboot if any configuration settings have changed:

This is a little drastic as a default since most applications will work just fine with changed configuration – maybe that’s the reason this code has gone away in the 1.3 SDK templates (more).

The Changed event gets fired after the configuration changes have been applied. Again the changes will get passed in just like in the Changing event. But from this point on RoleEnvironment.GetConfigurationSettingValue() will return the new values. You can still decide to recycle if some change was so drastic that you need a restart. You can use RoleEnvironment.RequestRecycle() for that (more).

As a rule of thumb: When you always use GetConfigurationSettingValue to read from configuration (and there is no bigger state involved) – you typically don’t need to recycle.

In the case of StarterSTS, I had to abstract away the physical configuration system and read the actual configuration (either from web.config or the Azure service configuration) at startup. I then cache the configuration settings in memory. This means I indeed need to take action when configuration changes – so in my case I simply clear the cache, and the new config values get read on the next access to my internal configuration object. No downtime – nice!

Gotcha
A very natural place to hook up the RoleEnvironment lifetime events is the RoleEntryPoint derived class. But with the move to the full IIS model in 1.3 – the RoleEntryPoint methods get executed in a different AppDomain (even in a different process) – see here.. You might no be able to call into your application code to e.g. clear a cache. Keep that in mind! In this case you need to handle these events from e.g. global.asax.

Saturday, December 25, 2010 6:46:54 AM UTC

Raf did some updates to his tool. It can now generate WIF/WCF certificateReference sections. Nice.

Blog post: http://www.iamraf.net/Tools/DeployManager-first-release-certificates-management
Direct link: DeployManager.exe

Friday, December 24, 2010 9:50:26 AM UTC

nice ;) thanks for all the feedback and testing!

Thursday, December 02, 2010 4:25:37 PM UTC

Back from TechEd – was a blast ;)

Here’s the recording of my talk:
http://www.msteched.com/2010/Europe/ARC303

Sunday, November 14, 2010 5:34:21 PM UTC

I just uploaded a new drop of StarterSTS.

This release has many changes and new features, e.g.:

• Built-in support for Windows Azure
• Caching
• New REST endpoint
• Federated Sign-Out
• Extended tracing (including real time tracing to a WCF service and logging of RST(R)s and tokens)

I will drill deeper into the new features in the forthcoming blog posts.

Please try it out and give me feedback.

Sunday, October 31, 2010 9:34:37 AM UTC

See the previous posts first.

So far we looked at the (simpler) scenario where a client acquires a token from an identity provider and uses that for authentication against a relying party WCF service.

Another common scenario is, that the client first requests a token from an identity provider, and then uses this token to request a new token from a Resource STS or a partner’s federation gateway.

This sounds complicated, but is actually very easy to achieve using WIF’s WS-Trust client support. The sequence is like this:

1. Request a token from an identity provider. You use some “bootstrap” credential for that like Windows integrated, UserName or a client certificate. The realm used for this request is the identifier of the Resource STS/federation gateway.
2. Use the resulting token to request a new token from the Resource STS/federation gateway. The realm for this request would be the ultimate service you want to talk to.
3. Use this resulting token to authenticate against the ultimate service.

Step 1 is very much the same as the code I have shown in the last post. In the following snippet, I use a client certificate to get a token from my STS:

To use a token to request another token is slightly different. First the IssuedTokenWSTrustBinding is used and second the channel factory extension methods are used to send the identity provider token to the Resource STS:

For this particular case I chose an ADFS endpoint for issued token authentication (see part 1 for more background). Calling the service now works exactly like I described in my last post.

You may now wonder if the same thing can be also achieved using configuration only – absolutely. But there are some gotchas. First of all the configuration files becomes quite complex. As we discussed in part 4, the bindings must be nested for WCF to unwind the token call-stack. But in this case svcutil cannot resolve the first hop since it cannot use metadata to inspect the identity provider. This binding must be supplied manually.

The other issue is around the value for the realm/appliesTo when requesting a token for the R-STS. Using the manual approach you have full control over that parameter and you can simply use the R-STS issuer URI. Using the configuration approach, the exact address of the R-STS endpoint will be used. This means that you may have to register multiple R-STS endpoints in the identity provider. Another issue you will run into is, that ADFS does only accepts its configured issuer URI as a known realm by default. You’d have to manually add more audience URIs for the specific endpoints using the ADFS Powershell commandlets.

I prefer the “manual” approach.

That’s it. Hope this is useful information.

Thursday, October 28, 2010 10:03:58 AM UTC

See the previous posts first.

WIF includes an API to manually request tokens from a token service. This gives you more control over the request and more flexibility since you can use your own token caching scheme instead of being bound to the channel object lifetime.

The API is straightforward. You first request a token from the STS and then use that token to create a channel to the relying party service. I’d recommend using the WS-Trust bindings that ship with WIF to talk to ADFS 2 – they are pre-configured to match the binding configuration of the ADFS 2 endpoints.

The following code requests a token for a WCF service from ADFS 2:

Afterwards, the returned token can be used to create a channel to the service. Again WIF has some helper methods here that make this very easy:

Why is this approach more flexible? Well – some don’t like the configuration voodoo. That’s a valid reason for using the manual approach. You also get more control over the token request itself since you have full control over the RST message that gets send to the STS.

One common parameter that you may want to set yourself is the appliesTo value. When you use the automatic token support in the WCF federation binding, the appliesTo is always the physical service address. This means in turn that this address will be used as the audience URI value in the SAML token. Well – this in turn means that when you have an application that consists of multiple services, you always have to configure all physical endpoint URLs in ADFS 2 and in the WIF configuration of the service(s).

Having control over the appliesTo allows you to use more symbolic realm names, e.g. the base address or a completely logical name. Since the URL is never de-referenced you have some degree of freedom here.

In the next post we will look at the necessary code to request multiple tokens in a call chain. This is a common scenario when you first have to acquire a token from an identity provider and have to send that on to a federation gateway or Resource STS.

Stay tuned.

Thursday, October 14, 2010 3:47:04 PM UTC

See parts 1, 2 and 3 first.

In this part we will finally build a client for our federated service.

There are basically two ways to accomplish this. You can use the WCF built-in tooling to generate client and configuration via the service metadata (aka ‘Add Service Reference’). This requires no WIF on the client side. Another approach would be to use WIF’s WSTrustChannelFactory to manually talk to the ADFS 2 WS-Trust endpoints. This option gives you more flexibility, but is slightly more code to write. You also need WIF on the client which implies that you need to run on a WIF supported operating system – this rules out e.g. Windows XP clients.

We’ll start with the metadata way. You simply create a new client project (e.g. a console app) – call ‘Add Service Reference’ and point the dialog to your service endpoint. What will happen then is, that VS will contact your service and read its metadata. Inside there is also a link to the metadata endpoint of ADFS 2. This one will be contacted next to find out which WS-Trust endpoints are available. The end result will be a client side proxy and a configuration file. Let’s first write some code to call the service and then have a closer look at the config file.

That’s all. The magic is happening in the configuration file.

When you in inspect app.config, you can see the following general configuration hierarchy:

• <client /> element with service endpoint information
• federation binding and configuration containing
• ADFS 2 endpoint 1 (with binding and configuration)
• ADFS 2 endpoint n (with binding and configuration)

(where ADFS 2 endpoint 1…n are the endpoints I talked about in part 1)

You will see a number of <issuer /> elements in the binding configuration where simply the first endpoint from the ADFS 2 metadata becomes the default endpoint and all other endpoints and their configuration are commented out. You now need to find the endpoint you want to use (based on trust version, credential type and security mode) and replace that with the default endpoint. That’s it.

When you call the WCF proxy, it will inspect configuration, then first contact the selected ADFS 2 endpoint to request a token. This token will then be used to authenticate against the service.

In the next post I will show you the more manual approach using the WIF APIs.

Thursday, October 14, 2010 1:37:16 PM UTC

In part 1 of this series I briefly gave an overview of the ADFS / WS-Trust infrastructure. In part 2 we created a basic WCF service that uses ADFS for authentication. This part will walk you through the steps to register the service in ADFS 2.

I could provide screenshots for all the wizard pages here – but since this is really easy – I just go through the necessary steps in textual form.

Step 1 – Select Data Source
Here you can decide if you want to import a federation metadata file that describes the service you want to register. In that case all necessary information is inside the metadata document and you are done. FedUtil (a tool that ships with WIF) can generate such metadata for the most simple cases. Another tool to create metadata can be found here. We choose ‘Manual’ here.

Step 2 – Specify Display Name
I guess that’s self explaining.

Step 3 – Choose Profile
Choose ‘ADFS 2 Profile’ here.

Step 4 – Configure Certificate
Remember that we specified a certificate (or rather a private key) to be used to decrypting incoming tokens in the previous post. Here you specify the corresponding public key that ADFS 2 should use for encrypting the token.

Step 5 – Configure URL
This page is used to configure WS-Federation and SAML 2.0p support. Since we are using WS-Trust you can leave both boxes unchecked.

Step 6 – Configure Identifier
Here you specify the identifier (aka the realm, aka the appliesTo) that will be used to request tokens for the service. This value will be used in the token request and is used by ADFS 2 to make a connection to the relying party configuration and claim rules.

Step 7 – Configure Issuance Authorization Rules
Here you can configure who is allowed to request token for the service. I won’t go into details here how these rules exactly work – that’s for a separate blog post. For now simply use the “Permit all users” option.

OK – that’s it. The service is now registered at ADFS 2. In the next part we will finally look at the service client.

Stay tuned…

Tuesday, October 12, 2010 2:53:56 PM UTC

OK – so let’s first start with a simple WCF service and connect that to ADFS 2 for authentication.

The service itself simply echoes back the user’s claims – just so we can make sure it actually works and to see how the ADFS 2 issuance rules emit claims for the service:

The ViewClaim data contract is simply a DTO that holds the claim information.

Next is the WCF configuration – let’s have a look step by step. First I mapped all my http based services to the federation binding. This is achieved by using .NET 4.0’s protocol mapping feature (this can be also done the 3.x way – but in that scenario all services will be federated):

Next, I provide a standard configuration for the federation binding:
